Juniper POLICY MANAGEMENT - CONFIGURATION GUIDE V11.1.X Configuration Manual page 175

host1(config)#rate-limit-profile VOICE_RATE two-rate hierarchical
host1(config-rate-limit-profile)#committed-rate 64000
host1(config-rate-limit-profile)#committed-action transmit unconditional
host1(config-rate-limit-profile)#exit
host1(config)#policy-parameter A hierarchical
host1(config-policy-parameter)#exit
host1(config)#ip policy-list IP_POL1
host1(config-policy-list)#classifier-group * external parent-group EPG1
parameter A
host1(config-policy-list-classifier-group)#rate-limit-profile VOICE_RATE
host1(config-policy-list-classifier-group)#exit
host1(config-policy-list)#exit
Create a policy list to attach to all other sessions.
3.
host1(config)#ip policy-list IP_POL2
host1(config-policy-list)#classifier-group * external parent-group EPG1
parameter A
host1(config-policy-list-classifier-group)#forward
host1(config-policy-list-classifier-group)#exit
host1(config-policy-list)#exit
Attach IP_POL1 to the voice session of first user and attach IP_POL2 to the other
4.
session for the same user. Specify the same ID for parameter A.
host1(config)#interface fastEthernet 3/0.1
host1(config-interface)#vlan id 1
host1(config-interface)#exit
host1(config)#interface ip 3/0.1.1
host1(config-interface)#ip policy-parameter hierarchical A 1
host1(config-interface)#ip policy input IP_POL1 statistics enable
host1(config-interface)#exit
host1(config)#interface fastEthernet 3/0.2
host1(config-interface)#vlan id 2
host1(config-interface)#exit
host1(config)#interface ip 3/0.2.1
host1(config-interface)#ip policy-parameter hierarchical A 1
host1(config-interface)#ip policy input IP_POL2 statistics enable
host1(config-interface)#exit
Attach IP_POL1 to the voice session of the second user and attach IP_POL2 to
5.
the other session for the same user. Specify a different ID for parameter A.
host1(config)#interface ip 3/0.1.2
host1(config-interface)#ip policy-parameter hierarchical A 2
host1(config-interface)#ip policy input IP_POL1 statistics enable
host1(config-interface)#exit
host1(config)#interface ip 3/0.2.2
host1(config-interface)#ip policy-parameter hierarchical A 2
host1(config-interface)#ip policy input IP_POL2 statistics enable
host1(config-interface)#exit
Example: Arbitrary Interface Groups Hierarchical Policy Configuration
Chapter 7: Creating Hierarchical Policies for Interface Groups
149
