Creating Policy Lists for Frame Relay
The following example creates a Frame Relay policy that on egress marks the DE bit
to 1, and on ingress colors frames with a DE bit of 1 as red.
1.
2.
3.
4.
color green
1 interface(s) found
atm policy-list
Create the policy list used to mark egress traffic, then create the classifier group
for packets conforming to CLACL frMatchDeSet. Add a rule that marks the DE
bit as 1.
host1(config)#frame-relay policy-list frOutputPolicy
host1(config-policy-list)#classifier-group frMatchDeSet
host1(config-policy-list-classifier-group)#mark-de 1
host1(config-policy-list-classifier-group)#exit
host1(config-policy-list)#exit
Create the policy list used for the ingress traffic. and create the classifier group
conforming to CLACL frMatchDeSet. Add a rule that colors the ingress traffic.
host1(config)#frame-relay policy-list frInputPolicy
host1(config-policy-list)#classifier-group frGroupA
host1(config-policy-list-classifier-group)#color red
host1(config-policy-list-classifier-group)#exit
host1(config-policy-list)#exit
Apply the policy lists.
host1(config)#interface serial 5/0:1/1.1
host1(config-subif)#frame-relay policy output frOutputPolicy statistics enabled
host1(config-subif)#ip address 10.0.0.1 255.255.255.0
host1(config-subif)#exit
host1(config)#interface serial 5/1:1/1.1
host1(config-subif)#frame-relay policy input frInputPolicy statistics enabled
host1(config-subif)#exit
Display interface information to view the applied policies.
host1#show frame-relay subinterface
Frame relay sub-interface SERIAL5/0:1/1.1, status is up
Number of sub-interface down transitions is 0
Time since last status change 03:04:59
No baseline has been set
In bytes: 660
In frames: 5
In errors: 0
In discards: 0
In unknown protos: 0
Frame relay policy output frOutputPolicy
Chapter 3: Creating Policy Lists
Out bytes: 660
Out frames: 5
Out errors: 0
Out discards: 0
Creating Policy Lists for Frame Relay
