Table 5: Ascend-Data-Filter Fields - Juniper POLICY MANAGEMENT - CONFIGURATION GUIDE V11.1.X Configuration Manual

Table 5 on page 47 lists the fields in the order in which they are specified in the
hexadecimal Ascend-Data-Filter attribute.

Table 5: Ascend-Data-Filter Fields

Action or Classifier
Type
Filter or forward
Indirection
Spare
Source IP address
Destination IP address
Source IP prefix
Destination IP prefix
Protocol
Established
Source port
Destination port
Source port qualifier
Format Comments
1 byte 1=IPv4
3=IPv6
1 byte 0=filter
1=forward
1 byte 0=egress
1=ingress
1 byte -
4 bytes for IPv4 -
16 bytes for IPv6
4 bytes for IPv4 -
16 bytes for IPv6
1 byte Type 1 = Number of leading zeros in the wildcard mask
Type 3 = Higher-order contiguous bits of the address that comprise
the network portion of the address
1 byte Type 1 = Number of leading zeros in the wildcard mask
Type 3 = Higher-order contiguous bits of the address that comprise
the network portion of the address
1 byte -
1 byte Non implemented
2 bytes -
2 bytes -
1 byte 0= no compare
1= less than
2= equal to
3= greater than
4= not equal to
Chapter 4: Creating Classifier Groups and Policy Rules
Using RADIUS to Create and Apply Policies Overview
47
