JUNOSe 11.1.x Policy Management Configuration Guide
The packet capture can also be done for any source and destination defined in the
classifier list. If the logging verbosity is set to low, you can obtain the following level
of detail from the packet capture:
INFO 02/20/2008 10:10:23 policyMgrPacketLog:
test icmp FastEthernet2/2.100 100.1.1.2 100.1.2.2 forwarded
INFO 02/20/2008 10:10:26 ppolicyMfrPacketLog:
test icmp FastEthernet2.2.100.100.1.2.2 100.1.1.2 forwarded
If the logging verbosity is set to medium or high, you can obtain the following level
of detal from the packet capture:
INFO 02/20/2008 10:15:11 policyMgrPacketLog: Classifier: test.1, prot: icmp,
intf:
0x0, len: 0x3e8, id: 0x714, flags: 0x0, ttl: 0x20, proto; 0x1, chksum: 0xc4fb,
forwarded
INFO 02/20/2008 10:15:14 ppolicyMfrPacketLog: classifier: test.1, prot: icmp,
intf: FastEthernet2/2.100, sa: 100.1.1.2 da: 100.1.2.2 version: 0x45, tos:
0x0, len: 0x3e8, id: 0xbe8, flags: 0x0, ttl: 0x7e, proto; 0x1, chksum: 0x6227,
forwarded
216
Packet Flow Monitoring Overview
host1(config)#log severity info policyMgrPacketLog
host1(config)#log severity info policyMgrPacketLog policy-list all
host(config)#ip policy-list test
host(config-policy-list)#classifier-group *
host1(config-policy-list-classifier-group)#log
host1(config)#interface fastEthernet 2/0.100
host1(config-if)#vlan id 100
host1(config-if)#ip address 100.1.1.1 255.255.255.0
host1(config-if)#ip policy input test
host1(config-if)#ip policy output test
FastEthernet2/2.100, sa: 100.1.1.2, da: 100.1.2.2 version: 0x45, tos:
