JUNOSe 11.1.x Policy Management Configuration Guide

Example: PPP Interfaces Hierarchical Policy Configuration

Figure 18 on page 155 shows the following example:
This example uses the following:
154
Example: PPP Interfaces Hierarchical Policy Configuration
committed rate: 500000 bps, committed burst: 8192 bytes (default)
peak rate: 5000000 bps, peak burst: 62500 bytes (default)
committed: 0 packets, 0 bytes, action: transmit conditional
conformed: 0 packets, 0 bytes, action: transmit conditional
exceeded: 0 packets, 0 bytes, action: drop
unconditional: 0 packets, 0 bytes
saturated: 0 packets, 0 bytes
host1#show ip interface atm 5/0.2
IP policy input P
classifier-group data entry 1, external parent-group epg1
aggregate-node forwarding
0 packets, 0 bytes
forward
external parent-group epg1 aggregate-node forwarding
rate-limit-profile rlpData
committed rate: 10000 bps, committed burst: 8192 bytes (default)
peak rate: 100000 bps, peak burst: 8192 bytes (default)
committed: 0 packets, 0 bytes, action: transmit conditional
conformed: 0 packets, 0 bytes, action: transmit conditional
exceeded: 0 packets, 0 bytes, action: drop
unconditional: 0 packets, 0 bytes
saturated: 0 packets, 0 bytes
Two dual-stack PPP user sessions are configured over the same VLAN interface.
Each PPP session corresponds to a dynamic user.
Each PPP user can send a combined IPv4 and IPv6 video traffic with a maximum
rate of 1 Mbps.
One of the subscribers, PPP user1, can send a default maximum rate of 3 Mbps
combined IPv4/IPv6 session traffic, whereas the other subscriber, PPP user2,
can send a default maximum rate of 5 Mbps combined IPv4/IPv6 session traffic.
I1 and I3 are interfaces where IPv4 policies are attached.
I2 and I4 are interfaces where IPv6 policies are attached.
PPP 1 is the PPP session of dynamic subscriber 1. I1 and I2 belong to this
subscriber.
PPP 2 is the PPP session of dynamic subscriber 2. I3 and I4 belong to this
subscriber.
vlan denotes the VLAN interface over which subscribers are configured.
At I1 and I3:
Classified Video Flow. VIDEO_RATE, Committed Rate: 1 Mbps
Peak Rate: 0 Mbps
