JUNOSe 11.1.x Policy Management Configuration Guide
Use the show classifier-list and show policy-list commands to view information
about the policy:
host1#show classifier-list
IP clin_1800020_00.1 ip 10.2.1.0 0.0.0.255 any
host1#show policy-list
IP Policy plin_ip_1800020
In this example, the Ascend-Data-Filter attribute is used to create RADIUS records
that configure two policies. The first policy is an input policy that filters all TCP packets
that come from a port greater than 9000 on host 10.2.1.1 and that go to any
destination. The second policy is an output policy that filters all UDP packets from
network 20.1.0.0 to host 10.2.1.1, port 3090.
Using the show classifier-list and show policy-list commands produces the following
information about the new policies:
host1#show classifier-list
IP clin_1800021_00.1 tcp 10.2.1.1 gt 9000 any
IP clout_1800021_01.1 udp 20.1.0.0 0.0.255.255 10.2.1.1 eq 3090
host1#show policy-list
IP Policy plin_ip_1800021
52
Examples: Using the Ascend-Data-Filter Attribute for IPv4 Subscribers
Classifier Control List Table
---------- ------- ---- -----
Administrative state: enable
Reference count: 1
Classifier control list: clin_1800020_00, precedence 100
filter
Referenced by interface(s):
ATM4/0.0 input policy, statistics enabled, virtual-router default
Referenced by profile(s):
No profile references
Ascend-Data-Filter = "01000100 0A020101 00000000 20000600 23280000
03000000"
Ascend-Data-Filter = "01000000 14010000 0A020101 10201100 00000C12
00020000"
Classifier Control List Table
---------- ------- ---- -----
Administrative state: enable
Reference count: 1
Classifier control list: clin_1800021_00, precedence 100
filter
Referenced by interface(s):
ATM4/0.0 input policy, statistics enabled, virtual-router default
Policy Table
------ -----
Policy Table
------ -----
