JUNOSe 11.1.x Policy Management Configuration Guide
4.
5.
host1# show mirror subscribers
Subscriber ID
------------------
lac:jwbooth@isptheatre.com
x:12000004:circuit id:45.y:12000004:remote id:89
x:12000001:pppoe agent circuit id:47
79:3a:02:00:00:02:3a:72:65:6d:6f:74:65:20:69:64:3a:35 agent-remote-id
6.
236
Example: Configuring CLI-Based User-Specific Mirroring
host1(config)#secure l2tp policy-list l2tp_toMirrorHQ
host1(config-policy-list)#classifier-group *
host1(config-policy-list-classifier-group)#mirror analyzer-ip-address
192.168.99.2 analyzer-virtual-router default analyzer-udp-port 6500
mirror-identifier 1 session-identifier 1
For DHCP and PPP subscribers:
host1(config)#secure ip policy-list secure-ipv4-policy
host1(config-policy-list)#classifier-group *
host1(config-policy-list-classifier-group)#mirror analyzer-ip-address 19.0.0.2
analyzer-virtual-router default analyzer-udp-port 2500 mirror-identifier 1
session-identifier 1
Configure packet mirroring for the subscriber and associate the secure policy
with the user.
For L2TP subscribers:
host1(config)#virtual-router lac
host1:lac(config)#mirror username jwbooth@isptheatre.com l2tp
secure-policy-list l2tp_toMirrorHQ
For DHCP and PPP subscribers:
host1(config)#mirror dhcp-option-82 agent-circuit-id "x:12000004:circuit
id:45" agent-remote-id "y:12000004:remote id:89" ip secure-policy-list
secure-ipv4-policy
host1(config)#mirror agent-circuit-id "x:12000001:pppoe agent circuit id:47"
ip secure-policy-list secure-ipv4-policy
host1(config)#mirror agent-remote-id hex
79:3a:02:00:00:02:3a:72:65:6d:6f:74:65:20:69:64:3a:35 ip
secure-policy-list secure-ipv4-policy
Now, when the subscriber logs in , the packet mirroring session starts and the
subscriber's replicated traffic is sent to the remote analyzer device.
Verify the packet-mirroring configuration.
----------
Verify the configuration of the secure policy.
host1# show secure policy-list
Secure L2TP Policy l2tp_toMirrorHQ
Administrative state: enable
ID Secure
Method Policy Type
-----------
username l2tp
dhcp-option-82 IP
agent-circuit-id IP
IP
Policy Table
------ -----
Secure Mirrored
Policy List Sessions
---------------- --------
l2tp_toMirrorHQ 1
secure-ipv4-policy 1
secure-ipv4-policy 1
secure-ipv4-policy 1
