Page 1 E-series™ Routing Platforms ERX™ Hardware Guide Release 7.0.x Juniper Networks, Inc. 1194 North Mathilda Avenue Sunnyvale, California 94089 408-745-2000 www.juniper.net Part Number: 162–xxxxx-00, Revision A00...
Page 2 The information in this document is current as of the date listed in the revision history. Juniper Networks assumes no responsibility for any inaccuracies in this document. Juniper Networks reserves the right to change, modify, transfer or otherwise revise this publication without notice.
Page 3 (g) distribute any key for the Software provided by Juniper to any third party; (h) use the Software in any manner that extends or is broader than the uses purchased by Customer from Juniper or an authorized Juniper reseller;...
Page 4 (or services are accessed by) the Software shall be a third party beneficiary with respect to this Agreement, and such licensor or vendor shall have the right to enforce this Agreement in its own name as if it were Juniper. In addition, certain third party software may be provided with the Software and is subject to the accompanying license(s), if any, of its respective owner(s).
Page 5: Table Of Contents
Table of Contents About This Guide Objectives ................xi Audience.
Page 6 Contacting Juniper Networks ........
Page 7 Table of Contents Chapter 5 Cabling E-series Routers Cabling Overview ..............51 Required Tools, Wires, and Cables .
Page 8 ERX 7.0.x Hardware Guide Cleaning the System..............82 Upgrading NVS Cards on SRP Modules .
Page 9 Table of Contents ERX-310 Power Cord Warnings (AC Model) ....... . .128 Equipment Rack Requirements.
Page 10 ERX 7.0.x Hardware Guide Table of Contents...
Page 11: About This Guide
About This Guide This preface provides the following guidelines for using this manual and related Juniper Networks, Inc., technical documents: Objectives on page xi Audience on page xi E-series Routers on page xii Documentation Conventions on page xii List of Technical Publications on page xiv...
Page 12 ERX 7.0.x Hardware Guide To use this guide, you need a broad understanding of networks in general, the Internet in particular, networking principles, and network configuration. You must also be familiar with one or more of the following Internet routing protocols: Border Gateway Protocol (BGP) Routing Information Protocol (RIP) Intermediate System-to-Intermediate System (IS-IS)
Page 13 About This Guide Table 1: Notice Icons Icon Meaning Description Informational note Indicates important features or instructions. Caution Indicates a situation that might result in loss of data or hardware damage. Warning Alerts you to the risk of personal injury or death.
Page 14 Table 3 lists and describes the E-series document set. A complete list of abbreviations used in this document set, along with their spelled-out terms, is provided in the JUNOSe System Basics Configuration Guide, Appendix A, Abbreviations and Acronyms . Table 3: Juniper Networks E-series Technical Publications Document Description E-series Hardware Guide...
Page 15 Release notes are included on the corresponding software CD and are available on the Web. Obtaining Documentation To obtain the most current version of all Juniper Networks technical documentation, see the products documentation page on the Juniper Networks Web site at http://www.juniper.net/...
Page 16 ERX 7.0.x Hardware Guide Requesting Support For technical support, open a support case with the Case Manager link at or call 1-888-314-JTAC (from the United States, http://www.juniper.net/support/ Canada, or Mexico) or 1-408-745-9500 (from elsewhere). Requesting Support...
Page 17 Part 1 Installing and Using E-series Routers E-series Overview on page 3 Unpacking and Inspecting E-series Routers on page 23 Installing E-series Routers on page 27 Installing Modules on page 35 Cabling E-series Routers on page 51 Powering Up E-series Routers on page 71 Accessing E-series Routers on page 75 Maintaining E-series Routers on page 81 Troubleshooting on page 99...
Page 18: Part 1 Installing And Using E-Series Routers
Installing and Using E-series Routers...
Page 19: E-Series Overview
Chapter 1 E-series Overview This chapter provides introductory information about the E-series routers. It contains the following sections: Overview on page 3 Where E-series Routers Fit In on page 3 E-series Routers on page 5 E-series Modules on page 10 Network Management Tools on page 17 Redundancy Features on page 17 Overview...
Page 20 ERX 7.0.x Hardware Guide Figure 1: E-series Router Communicating over T1/T3 Lines Internet Remote Remote T1/T3 Core access access router router router Desktop Desktop Figure 2: E-series Router Communicating over DSL Lines Internet Remote Core access router router Home office DSLAM Home office Desktop...
Page 21: E-Series Routers
E-series Overview E-series Routers Five models of E-series routers are available: ERX-1440 router ERX-1410 router ERX-710 router ERX-705 router ERX-310 router All models use the same software. However, the specific model determines the: Combination of line modules supported Conditions for line rate performance of line modules Type, capacity, and number of SRP modules used ERX-14xx Models NOTE: In the E-series documentation, the term ERX-14xx models refers to both...
Page 22 ERX 7.0.x Hardware Guide Internally, the ERX-1440 chassis differs from the ERX-1410 chassis, and includes a special midplane for the 40-Gbps SRP module. Installation procedures and operating procedures are identical for both systems. All ERX-7xx/14xx models use the same SRP I/O module, but different power input modules are used.
Page 23: Erx-7Xx Models
E-series Overview Figure 5: ERX-14xx Model, Rear View Fan tray module SRP I/O module Power input module Cable management bracket Plenum ERX-7xx Models NOTE: In the E-series documentation, the term ERX-7xx models refers to both the ERX-705 router and the ERX-710 router. The terms ERX-705 router and ERX-710 router refer to the specific models.
Page 24 ERX 7.0.x Hardware Guide The ERX-705 chassis is the same as the ERX-710 chassis (see Figure 6 and Figure 7). The chassis contains seven slots to accommodate modules. Installation procedures and operating procedures are identical for both systems. All ERX-7xx/14xx models use the same SRP I/O module, but different power input modules are used.
Page 25: Erx-310 Router
E-series Overview ERX-310 Router The ERX-310 router is a low-end platform that supports all of the same services as the ERX-7xx/14xx models, but with smaller capacity and scaling capabilities. Like the ERX-7xx/14xx models, the ERX-310 router uses the same software architecture, providing a single IP entry point into the network with the same IP-based protocols and services that are available on other E-series routers.
Page 26: E-Series Modules
ERX 7.0.x Hardware Guide Figure 9: ERX-310 Router, Rear View (AC Model) I/O module SRP I/O module ESD grounding jack AC power inputs and switches A and B Grounding posts Figure 10: ERX-310 Router, Rear View (DC Model) module SRP I/O module ESD grounding jack DC power inputs...
Page 27: Srp Module
E-series Overview Figure 11: Modules in ERX-14xx Model SRP I/O I/O modules module I/O modules Connection via passive midplane Line modules SRP modules Line modules NOTE: Some line modules require a minimum amount of memory to be used with JUNOSe Release 5.3.0 or a higher-numbered release. Refer to the E-series Module Guide for line module specifications.
Page 28 ERX 7.0.x Hardware Guide Figure 12: ERX-7xx/14xx SRP Module Fabric board Ejector Midplane connectors Status LEDs Board reset button NMI button PCMCIA NVS card System processor board E-series Modules...
Page 29: Module Details
E-series Overview Figure 13: ERX-310 SRP Module Ejector Midplane connectors Status LEDs PCMCIA NVS card Board reset button Integrated fabric system processor board NMI button Module Details ERX-7xx/14xx models use up to two redundant SRP modules operating in an active/standby configuration. ERX-310 routers use only one SRP module. An SRP module must be present for any system to boot.
Page 30: Srp Module Redundancy
If you remove the card while data is being written to or copied from the NVS card, data may be lost or corrupted. Therefore, Juniper Networks strongly recommends that you shut down the router before removing a PCMCIA NVS card.
Page 31: Module Details
E-series Overview Module Details The SRP module provides standard craft management interfaces, including: 10/100Base-T—Enables access to the E-series router for Ethernet management functions via CLI or SNMP, for example. RS-232—Provides a serial connection for monitoring the system’s hardware configuration through a PC (running terminal emulation software) or ASCII terminal.
Page 32: Packet Classification
ERX 7.0.x Hardware Guide Figure 14: Representative Line Module Ejector Status LEDs Midplane connectors Board reset button NMI button Packet Classification Most line modules support packet classification on ingress (some non-ASIC line modules do not). A classification engine on the line module matches specific fields (such as source and destination IP address, source and destination port, and protocol), the ingress IP interface, layer 2 fields, or some combination of these against user-configured filters at wire speed.
Page 33: Network Management Tools
The system offers a complete SNMP interface for configuration, status, and alarm reporting. The system supports both Standard and Enterprise MIBs (Management Information Bases). The Juniper Networks E-series Enterprise MIB is ASN.1 notated for easy importing into third-party SNMP management applications. For more information, see JUNOSe System Basics Configuration Guide, Chapter 3, Configuring SNMP.
Page 34: Nvs Cards
ERX 7.0.x Hardware Guide After you install two SRP modules, the modules negotiate for the primary role. A number of factors determine which module becomes the primary; however, preference is given to the module in the lower-numbered slot. The SRP modules record their latest roles and retain them the next time you switch on the system.
Page 35 E-series Overview Guide. In this scheme, an extra line module in a group of identical line modules provides redundancy in case of line module failure. To use this feature, you need a: Spare line module Redundancy midplane Redundancy I/O module A redundancy midplane may cover 3–6 slots.
Page 36: Power
ERX 7.0.x Hardware Guide Figure 15: Data Flow When a Spare Line Module Is Active Redundancy I/O module Primary I/O module Ž Œ Midplane Redundancy midplane 1. A packet arrives at the primary I/O module. Spare line module 2.
Page 37: Fans
E-series Overview Fans Forced air-cooling keeps the temperature of the E-series modules and components within normal operating limits. In ERX-14xx models, six cooling fans are located in a tray at the top of the router (see Figure 4). In ERX-7xx models, four cooling fans are located in a tray on one side of the router (see Figure 6).
Page 38 ERX 7.0.x Hardware Guide Redundancy Features...
Page 39: Unpacking And Inspecting E-Series Routers
A mechanical lift, or at least two people to assist in lifting Unpacking ERX-14xx Models ERX-14xx models come boxed, bolted, and strapped to a skid. For your convenience, Juniper Networks recommends that you unpack the E-series router in the location where you want to install it. Unpacking ERX-14xx Models...
Page 40: Unpacking Erx-7Xx Models And Erx-310 Routers
Unpacking ERX-7xx Models and ERX-310 Routers ERX-7xx models and ERX-310 routers are shipped boxed, but not attached to a skid. For your convenience, Juniper Networks recommends that you unpack the E-series router in the location where you want to install it.
Page 41: Inspecting E-Series Router Components And Accessories
Contact your Juniper Networks sales representative or reseller. Contacting Juniper Networks Please contact Juniper Networks at 1-888-314-JTAC (within the United States) or 408-745-9500 (from outside the United States), or contact your sales representative if you have any questions or concerns. See “Customer Support”...
Page 42: The Next Step
ERX 7.0.x Hardware Guide The Next Step To familiarize yourself with the electrical, environmental, and other guidelines and requirements for installing E-series routers, turn to . If you are familiar with these guidelines and requirements, turn to “Installing E-series Routers” on page 27. The Next Step...
Page 43: Installing E-Series Routers
Chapter 3 Installing E-series Routers This chapter describes how to install E-series routers in a rack. It contains the following sections: Before You Begin on page 27 Freestanding Installation on page 27 Rack-Mounted Installation on page 28 The Next Step on page 33 Before You Begin Before installing E-series routers, be sure you: Have a plan for installing E-series routers.
Page 44: Rack-Mounted Installation
Power switches SRP I/O module Rack-Mounted Installation Juniper Networks recommends that you use a standard EIA distribution rack. Refer to “Equipment Rack Requirements” on page 128 in “Installation Guidelines and Requirements” on page 125, for detailed rack information. Installation Guidelines...
Page 45 ERX-7xx model or ERX-310 router and the ERX-14xx model so that the air can circulate between the systems (see Figure 54). This plenum is available from Juniper Networks.
Page 46: Safety Guidelines
ERX 7.0.x Hardware Guide Figure 18: E-series Routers Installed in Recommended Order Safety Guidelines Observe the following safety guidelines when mounting the router in a rack. WARNING: Install equipment in the rack from the bottom upward. This will maintain the stability of the rack and reduce the chance that the rack will tip over. WARNING: Three people are required to install the E-series router in a rack: two to lift the system into position and one to screw it to the rack.
Page 47 Installing E-series Routers CAUTION: Evaluate the overall loading of the branch circuit before you install any equipment into a rack. WARNING: Connect the E-series router or rack to ground (earth), and ensure that a reliable grounding path is maintained in the rack. WARNING: Do not work on the system or connect or disconnect cables during lightning activity.
Page 48: Preparing The Equipment Racks
ERX 7.0.x Hardware Guide Preparing the Equipment Racks Following your installation plan, use a tape measure and marking pen to measure and mark space on each equipment rack for each E-series router component. Horizontal spacing should follow NEBS requirements. If you choose not to install a plenum, be sure to include 2 U of space between each chassis to allow for proper exhaust.
Page 49: The Next Step
Installing E-series Routers The Next Step After you finish installing the router: If you need to install any modules, turn to “Installing Modules” on page 35. If the router was delivered with the modules already installed, turn to “Cabling E-series Routers” on page 51, for instructions on connecting cables. The Next Step...
Page 50 ERX 7.0.x Hardware Guide The Next Step...
Page 51: Installing Modules
Chapter 4 Installing Modules This chapter describes how to install and remove E-series modules. For information about managing installed modules, see JUNOSe System Basics Configuration Guide, Chapter 5, Managing Line Modules and SRP Modules. This chapter contains the following sections: Overview on page 35 Safety Guidelines on page 40 Installing SRP I/O and SRP Modules on page 41...
Page 52: Slot Groups
ERX 7.0.x Hardware Guide Figure 19: Orientation of Line Modules in E-series Routers ERX-7xx model ERX-14xx model ERX-310 router For details about available line modules and compatibility between line modules and SRP modules, see E-series Module Guide. Slot Groups The slots in the ERX-1410 router and the ERX-7xx models are divided into groups. The number of groups and number of slots per group depend on the system.
Page 53: Slot Groups For The Erx-7Xx Models
Installing Modules Figure 20: ERX-1410 Slot Groups Chassis slots 1 2 3 4 8 9 10 11 12 13 Slot Slot Slot Slot group 1 group 2 group 3 group 4 Slot Groups for the ERX-7xx Models A slot group in an ERX-7xx model comprises one slot or two adjacent slots. The groups for an ERX-7xx model consist of the following slots (Figure 21): Slot group 1—Slots 2 and 3 Slot group 2—Slot 4...
Page 54: Combinations Of Line Modules In Slot Groups
ERX 7.0.x Hardware Guide Combinations of Line Modules In Slot Groups For information about allowed combinations of line modules in slot groups, see JUNOSe System Basics Configuration Guide, Chapter 5, Managing Line Modules and SRP Modules. OC48 Line Modules The ERX-1440 router with the SRP-40G+ SRP module supports OC48 line modules.
Page 55 Installing Modules Figure 22: Connecting the Wrist Strap to the ERX-310 Router (Rear) Antistatic wrist strap ESD grounding jack Table 4: Grounding Jack Locations E-series Router Location ERX-14xx model Front: inside front bezel in lower-left corner Rear: upper-right corner ERX-7xx model Rear: lower-right corner ERX-310 router Front: lower-left corner...
Page 56: Order Of Installation
ERX 7.0.x Hardware Guide CAUTION: If you meet strong resistance when attempting to seat the module using the ejectors, remove it from the chassis and confirm that the slot is one designed to hold the module. Then check, if applicable, that the module matches its corresponding module (I/O module or line module).
Page 57: Installing Srp I/O And Srp Modules
Doing so may cause electric shock and serious burns. WARNING: Never attempt to repair parts of modules yourself. Only trained customer service personnel are authorized to service parts. Call Juniper Networks Customer Service to make arrangements to return defective modules for repair.
Page 58: Installing An Srp I/O Module
ERX 7.0.x Hardware Guide NOTE: Install the SRP I/O module before you install the SRP module; otherwise, the system diagnostics will fail. Installing an SRP I/O Module To install an SRP I/O module: Ground yourself by using an antistatic wrist strap or other device. With a Phillips screwdriver, loosen the captive screws that secure the blank faceplate covering the empty chassis slot, if present, and remove the faceplate.
Page 59 Installing Modules Remove the SRP module from its antistatic bag. Verify that the ejectors are in the open position, as shown in Figure 23. Figure 23: Ejectors in the Open Position Œ Opened Closed Closed Œ Opened Slide the module into the chassis by placing it between the guides of the selected slot and pushing the module until it stops.
Page 60: Installing Line And I/O Modules
ERX 7.0.x Hardware Guide Insert the module into the backplane by simultaneously depressing both ejectors (as shown in Figure 23) and exerting forward pressure on the module. Tighten the module’s captive screws using a Phillips screwdriver. Alternately turn each screw several times before tightening them completely to allow the module to sit correctly.
Page 61: Removing A Line Module, Srp Module, Or Srp I/O Module
Installing Modules Table 6: Module Slot Assignments (continued) E-series Router Module Slot ERX-7xx model Install modules in slots 2–6 ERX-310 router Install modules in slots 1–2 With a Phillips screwdriver, loosen the screws that secure the blank faceplate covering the empty chassis slot, if present, and remove the faceplate. Remove the module from its antistatic bag.
Page 62 ERX 7.0.x Hardware Guide To remove a line module, SRP module, or SRP I/O module: For SRP modules and SRP I/O modules, issue the appropriate halt command (halt, halt primary-srp, or halt standby-srp). See JUNOSe System Basics Configuration Guide, Chapter 5, Managing Line Modules and SRP Modules for information about the halt commands.
Page 63: Installing Components For Line Module Redundancy
Installing Modules Cover the empty chassis slot with a blank faceplate, and tighten the faceplate’s captive screws using a Phillips screwdriver. Turn both screws several times before tightening them completely. If you remove an I/O module and not the corresponding line module, the line module reboots.
Page 64: Installing The Redundancy Midplane
ERX 7.0.x Hardware Guide Install the spare line module in the lowest-numbered slot of the redundancy group. Install the other line modules in the remaining slots. (See “Installing Line and I/O Modules” on page 44). Installing the Redundancy Midplane To install the redundancy midplane in a redundancy group: CAUTION: If you do not use the halt command before removing or powering down an SRP, the system’s NVS card may become corrupted.
Page 65: Installing The I/O Modules
Installing Modules Figure 25: Installing a Redundancy Midplane Redundancy midplane Installing the I/O Modules To install the I/O modules in a redundancy group: Install the redundancy I/O module in the lowest-numbered slot of the redundancy group. CAUTION: When setting up a redundancy group with line modules, be sure to install the redundancy I/O module in the lowest-numbered slot of the redundancy group.
Page 66: Verifying The Installation
ERX 7.0.x Hardware Guide Verifying the Installation To verify that the installation is complete: After you have cabled the system for power (see “Cabling E-series Routers” on page 51), turn on the power switches. The system reboots. Issue the show redundancy command, and verify that the display shows the redundancy hardware.
Page 67: Cabling E-Series Routers
Chapter 5 Cabling E-series Routers This chapter describes how to cable an E-series router. Before you cable the router, ensure that you have completed all installation instructions identified in previous chapters. This chapter contains the following sections: Cabling Overview on page 51 Required Tools, Wires, and Cables on page 53 Cabling the SRP I/O Module on page 54 Cabling the E-series Router for Power on page 58...
Page 68 ERX 7.0.x Hardware Guide NOTE: Juniper Networks recommends that you use shielded cables where appropriate. Figure 26: E-series Ports and Connectors (ERX-14xx Model Shown) SRP I/O module Alarm leads (slot positions 6 and 7) External timing ports (Europe) External timing ports (North America)
Page 69: Required Tools, Wires, And Cables
Cabling E-series Routers Required Tools, Wires, and Cables Cabling your system should take only a few minutes. You will need the items listed below and in Table 7 for proper installation. 1/8" flathead screwdriver 3/8" wrench or 3/8" nut-driver No. 2 Phillips screwdriver Ground wires—We recommend a minimum of 10-AWG ground wire.
Page 70: Cabling The Srp I/O Module
ERX 7.0.x Hardware Guide Cabling the SRP I/O Module Before powering up the E-series router, you must set up a management console. The console enables you to communicate with your system during the power-up process and to manage your system using the command line interface (CLI). When connecting a console directly to the SRP I/O module, use a cable appropriate for your terminal connector.
Page 71 Cabling E-series Routers There are two input ports on the SRP I/O module for external clock sources. These ports provide a way to ensure that the E-series router system clock remains synchronized with the network’s system clock. The primary clock is labeled A;...
Page 72 ERX 7.0.x Hardware Guide Figure 27: ERX-14xx Model SRP I/O Module MINOR 26-AWG wire MAJOR CRITICAL E1 75 OHM BNC (Europe) CLOCK IN Wire-wrap connectors (North America, Japan) T1 100 OHM CLOCK IN 10/100 BASE T RS-232 DB-9 To connect the clock source input ports: Depending on the connector type, complete one of the following tasks: E1: Attach the BNC connector to Clock A’s external timing port.
Page 73: Management Ports
Cabling E-series Routers NOTE: You can use a wire-wrap gun to attach wires to pins. Attach the opposite end of the external timing cable or wires to your network’s clock source A. Repeat Steps 1 and 2 for the Clock B connections. Management Ports NOTE: This section applies to all E-series routers.
Page 74: Connecting To The Network
ERX 7.0.x Hardware Guide Connecting to the Network To connect the E-series router to the network: Insert an Ethernet cable (RJ-45) connector into the 10/100Base-T (RJ-45) port on the SRP I/O module until it clicks into place. Connect the other end of the cable to the appropriate Ethernet network for an out-of-band connection.
Page 75 Cabling E-series Routers Table 9: Power Input Module Cables and Wires Needed Cable/Wire From ERX-14xx models One 10-AWG ground wire Power input module ground terminal Termination ground Two 8-AWG wire leads Power input module Power A –48 VDC Appropriate leads on power source No.1 and RTN leads Two 8-AWG wire leads Power input module Power B –48 VDC...
Page 76 ERX 7.0.x Hardware Guide Table 9: Power Input Module Cables and Wires Needed (continued) Cable/Wire From Two 14-AWG wire leads (DC model only) Power input module Power B –48 VDC Appropriate leads on power source No.2 and RTN leads One AC power cord (AC model only) Power input module AC power IEC Appropriate AC power supply receptacle...
Page 77: Task 1: Turn Off All E-Series Router Power
Cabling E-series Routers Task 1: Turn Off All E-series Router Power Before starting, you must switch all E-series router power switches to OFF. To turn off the router, push each power switch to the OFF position. Task 2: Connect the Grounding Cables All E-series routers have two grounding studs located in the rear of the chassis, near the power inputs.
Page 78 ERX 7.0.x Hardware Guide Be sure you have completed Task 1 and Task 2 in the previous sections. If applicable, loosen the screws from the clear power input module cover and remove it. WARNING: Be sure the power source is turned off, the E-series router is turned off, and proper grounding wires are attached before continuing with this procedure.
Page 79: Router (Ac Model)
Cabling E-series Routers Figure 30: ERX-310 Router, Rear View (DC Model) DC power DC power Power A leads input A input B Ground Power A Power B switch switch ERX-310 router (AC model) Insert the power cord into the AC power IEC receptacle (see Figure 31). Insert the other end of the power cord into an appropriate AC power source.
Page 80: Cabling I/O Modules
ERX 7.0.x Hardware Guide Cabling I/O Modules The following section illustrates the common connector types used with E-series I/O modules. For information about the connectors on the different line modules, see E-series Module Guide. BNC Connectors Figure 32: I/O Module with BNCs Port 0 Port 1 HSSI Connectors...
Page 81: Rj-45 Connectors
Cabling E-series Routers Figure 33: HSSI I/O Module with 50-Pin HSSI Connector HSSI-3 Port 0 RJ-45 Connectors When inserting an RJ-45 connector, be sure it clicks into the port. Figure 34: I/O Module with RJ-45 Connector 10/100 FE-2 Port 0 RJ-48C Connectors When inserting an RJ-48C connector, be sure it clicks into the port.
Page 82: Lc Duplex Connectors
ERX 7.0.x Hardware Guide Figure 35: I/O Module with RJ-48C Connectors Port 0 LC Duplex Connectors In accordance with EN60825-1, Safety of Laser Products - Part 1: Equipment Class, Requirements, and User’s Guide (2001), multimode I/O modules with LC connectors are defined as follows: CLASS 1 LED PRODUCT.
Page 83 Cabling E-series Routers CLASS 1 LED PRODUCT. In accordance with EN60825-1, Safety of Laser Products - Part 1: Equipment Class, Requirements, and User’s Guide (2001), single-mode I/O modules with SC connectors are defined as follows: CLASS 1 LASER PRODUCT. WARNING: Do not look directly into SC-style fiber connectors. The fiber-optic laser used in single-mode fiber (SMF) meets the regulatory requirements for casual exposure to the eye;...
Page 84: Smb Connectors
ERX 7.0.x Hardware Guide Figure 36: I/O Module with SC Full Duplex Connectors Port 0 Port 1 SMB Connectors To cable I/O modules with SMB connectors, pull back the metal sheath on the connector, insert the connector into the selected port, and release the metal sheath. Cabling I/O Modules...
Page 85: X.21/V.35 Connectors
Cabling E-series Routers Figure 37: I/O Module with SMB Connectors CT3/T3 Port 0 X.21/V.35 Connectors Four cables are available for the X.21/V.35 I/O modules: X.21 DCE cable (terminated with 8 female X.21 connectors) X.21 DTE cable (terminated with 8 male X.21 connectors) V.35 DCE cable (terminated with 8 female V.35 connectors) V.35 DTE cable (terminated with 8 male V.35 connectors) Each 200-pin proprietary socket on the I/O module provides connections to 8...
Page 86: Redundant Ports
ERX 7.0.x Hardware Guide Figure 38: X.21/V.35 Module with 50-Pin X.21/V.35 Connector X.21/V.35 Port 0 Redundant Ports Some modules have redundant ports. See the E-series Module Guide for specifications. Cabling both ports provides a redundant path to the E-series module. CAUTION: For port redundancy to operate correctly on a GE I/O module that supports SFPs, both the primary and redundant ports on an E-series GE I/O module must use the same type of SFP.
Page 87: Powering Up E-Series Routers
Chapter 6 Powering Up E-series Routers This chapter describes how to power up an E-series router and determine if it has booted properly. It contains the following sections: Before You Power Up the System on page 71 Powering Up on page 71 Status LEDs on page 73 Powering Down on page 73 The Next Step on page 73...
Page 88: Initialization Sequence
ERX 7.0.x Hardware Guide NOTE: This procedure assumes that the system is already connected to a power source. See “Cabling E-series Routers” on page 51. CAUTION: Evaluate the overall loading of the branch circuit before you install any equipment into a rack. To power up the system: Verify that the power source is operational and turned on.
Page 89: Status Leds
Powering Up E-series Routers Status LEDs Upon initial powerup, the components of the E-series router run boot code, go through a series of self diagnostic tests, and synchronize with each other. When the tests are complete, use the LEDs on each module to determine the status of the router.
Page 90 ERX 7.0.x Hardware Guide The Next Step...
Page 91: Accessing E-Series Routers
Chapter 7 Accessing E-series Routers This chapter discusses how to access the system to manage it. Managing your router includes both configuring and monitoring it. For basic information on the management of the system, see JUNOSe System Basics Configuration Guide, Chapter 4, Managing the System.
Page 92: Console Port Setup
ERX 7.0.x Hardware Guide Console Port Setup A console terminal (PC, Macintosh, or UNIX workstation) can be connected directly to the SRP I/O module via the RS-232 terminal port. When you connect a console directly to the system, you can configure the system without an IP address. To communicate with the system, you must have a terminal emulation program running on your PC or Macintosh.
Page 93 Accessing E-series Routers To connect a console directly to the system: Connect the female DB-9 connector to the RS-232 port on the system’s SRP I/O module. See Figure 39. Figure 39: E-series Routers Management Ports ERX-310 Router SRP I/O module SRP I/O module T1 100 OHM...
Page 94: Assigning An Ip Address
ERX 7.0.x Hardware Guide Assigning an IP Address When your console is ready to communicate with the system, power up the system (see “Powering Up E-series Routers” on page 71), and set an IP address for the system. The system powers up in User Exec mode. To assign an IP address: Enter the enable command at the User Exec prompt.
Page 95 Accessing E-series Routers Enter the configure command. host1#configure terminal Enter configuration commands, one per line. End with CNTL/Z. host1(config)# The system is now in Global Configuration mode. Enter the line command. host1(config)#line vty 0 4 host1(config-line)# The system is now in Line Configuration mode. Disable the password.
Page 96: Snmp
ERX 7.0.x Hardware Guide CAUTION: Do not change the IP address for the Ethernet interface that you are using to communicate with the system. If you change the address, you will lose the Telnet session. SNMP The system supports Simple Network Management Protocol (SNMP), a standard management protocol for IP networks.
Page 97: Maintaining E-Series Routers
This chapter lists the tools, items, and steps needed for installing and uninstalling E-series components. Other maintenance procedures must be performed by an authorized Juniper Networks technician. This chapter contains the following sections: Required Tools and Items on page 81...
Page 98: Storing Modules And Components
ERX 7.0.x Hardware Guide Storing Modules and Components CAUTION: Failure to store electronic modules and components correctly may lead to damage of these items. Retain the packaging in which a module or component was shipped, and use this packaging to store the item. Modules are shipped in antistatic bags and protective packaging.
Page 99: Upgrading Nvs Cards On Srp Modules
Maintaining E-series Routers Upgrading NVS Cards on SRP Modules This section describes how to install higher-capacity NVS cards on SRP modules. The procedure you use depends on the number of SRP modules in the system. A new NVS card will contain the software release you ordered. NOTE: The new NVS card must contain the same software release that you are running on the system.
Page 100: Upgrading A System That Contains Two Srp Modules
ERX 7.0.x Hardware Guide Replace the NVS card on the SRP module (see “Replacing an NVS Card” on page 85). Power up the system (see “Powering Up E-series Routers” on page 71). Upgrading a System That Contains Two SRP Modules In a system that contains two SRP modules, you can upgrade the NVS cards on the SRP modules without powering down the system.
Page 101: Replacing An Nvs Card
Maintaining E-series Routers host1#synchronize When the SRP modules are synchronized, force the redundant SRP module to take over from the primary SRP module. host1#srp switch Halt the redundant (former primary) SRP module. host1#halt standby-srp Immediately remove the former primary SRP module. Repeat Steps 4–8 for the former primary SRP module.
Page 102: Upgrading Memory On Srp Modules
ERX 7.0.x Hardware Guide Insert the new NVS card into the slot. Push the new NVS card as far as you can in the slot. When you push the card far enough, it will click into place. Replace the faceplate on the NVS card slot. Upgrading Memory on SRP Modules This section describes how to upgrade memory on SRP modules.
Page 103: Checking The Memory Installed
Maintaining E-series Routers Checking the Memory Installed Before you install the new memory, issue the show hardware command to check how much memory is installed. Each ERX-7xx/14xx model SRP module should currently use at least 256 MB of memory. You will need one upgrade kit for each SRP module in the system.
Page 104 ERX 7.0.x Hardware Guide Figure 41: SODIMM Sockets on the SRP-5 and SRP-10 Module Cream ceramic connector Empty SODIMM socket SODIMM 1. Align notches in SODIMM and connector. 2. Push SODIMM into connector at an angle of approximately 45 degrees. 3.
Page 105: Verifying The Upgrade
Maintaining E-series Routers Repeat Steps 2 through 3 with the other SODIMM. Repeat Steps 1 through 4 for the other SRP module, if present. Verifying the Upgrade To verify that the upgrade is complete: Place the SRP modules in the chassis. The SRP modules will reboot.
Page 106: Installing Sfps
ERX 7.0.x Hardware Guide Put the antistatic wrist strap on your wrist, and connect the strap to the ESD grounding jack on the system. Disconnect the cables from one of the SFPs on the module. Identify the release mechanism for the SFP. Different SFPs use different release mechanisms (see Figure 43).
Page 107 Maintaining E-series Routers Put the antistatic wrist strap on your wrist, and connect the strap to the ESD grounding jack on your system. Identify the following items on the SFP (see Figure 44): The connection circuitry on the base The cable connectors on the front The cable connectors will be protected by a dust cover.
Page 108 ERX 7.0.x Hardware Guide Figure 45: Installing an SFP on an E-series GE I/O Module TX and RX markings on I/O module Connection circuitry on base of SFP Insert the SFP as far as you can into the I/O module. The SFP should slide smoothly into the I/O module and should click into place.
Page 109: Verifying The Installation
Maintaining E-series Routers Verifying the Installation When you have replaced the SFPs and connected the cables, issue the show interface gigabitEthernet command for each interface to check that the interface is operational (up). Field descriptions gigabitEthernet interfaceSpecifier —Status of the hardware on this interface up—Hardware is operational down—Hardware is not operational...
Page 110 ERX 7.0.x Hardware Guide until a new fan tray is available. Operating an E-series router with inadequate air circulation may damage the modules. CAUTION: Do not use the fan tray handle to carry the fan tray assembly. Use the handle only to pull the tray out of the chassis. Figure 46: Fan Tray in ERX-14xx Model Fan tray Figure 47: Fan Tray in ERX-310 Router...
Page 111: Removing The Fan Tray
Maintaining E-series Routers Removing the Fan Tray To remove the fan tray: (ERX-14xx models only) Place a flathead screwdriver in the groove where the top bezel meets the chassis on the top of the system, and lever the top bezel off the front of the system. With an appropriate screwdriver, loosen the captive screws located at the corners of the fan tray.
Page 112: Installing A Cable-Management Bracket On Erx-7Xx Models
ERX 7.0.x Hardware Guide Alternate between screws when tightening them to ensure that the electrical connectors at the back of the tray fit tightly. (ERX-14xx model only) Push the top bezel back on the front of the system. Figure 48: Fan Tray in ERX-7xx Model Installing a Cable-Management Bracket on ERX-7xx Models A cable-management bracket can be installed to accommodate cables of different sizes on ERX-7xx models.
Page 113 Maintaining E-series Routers Figure 49: Attaching a Cable Management Bracket Mount in this area for smaller cables Mount here for wider X.21/V.35 cables Perforated area Front of ERX-7xx model Installing a Cable-Management Bracket on ERX-7xx Models...
Page 114 ERX 7.0.x Hardware Guide Installing a Cable-Management Bracket on ERX-7xx Models...
Page 115: Troubleshooting
Chapter 9 Troubleshooting This chapter explains how you can troubleshoot a specific problem, such as abnormal LED activity or no system power, when you power up the router. It contains the following sections: Diagnosing Problems on page 99 Troubleshooting Power Failures on page 100 Understanding Status LEDs to Troubleshoot on page 100 Monitoring Temperatures of Modules on page 109 Resetting Line Modules and SRP Modules on page 110...
Page 116: Troubleshooting Power Failures
See to “System Specifications” on page 113. If the system still does not operate, contact Juniper Networks Customer Service. System shuts down. Temperature too high NOTE: The following actions apply to all of the possible problems.
Page 117: Led Identification
Troubleshooting with LED activity so that you can easily detect and correct a module-related problem with minimal or no system downtime. LED Identification The system’s modules have two sets of status LEDs. The top set indicates overall router and module status. The bottom set indicates module-specific status, such as port status (line modules) or fan status (SRP module).
Page 118 ERX 7.0.x Hardware Guide Table 11: LED Identification and Activity Descriptions (continued) LED Location LED Label LED Indicator LED Color OFF to ON ON to OFF LINK Ethernet line Ethernet Green Ethernet link up Ethernet link modules down ACTIVITY Green Ethernet Blinks when No Ethernet traffic...
Page 119 Troubleshooting Table 11: LED Identification and Activity Descriptions (continued) LED Location LED Label LED Indicator LED Color OFF to ON ON to OFF Port status Port not X.21/V.35 line ACTIVE Green Port configured configured module LOOPBK Port status Port not in Yellow Port in local loopback...
Page 120 ERX 7.0.x Hardware Guide Figure 50: SRP Module LEDs Status LEDs Status LEDs NOTE: The primary SRP module illuminates the REDUNDANT LED only when the SRP module detects that there is a secondary or standby SRP module online. The standby SRP module monitors an activity signal from the primary SRP module to determine its state;...
Page 121 Troubleshooting Figure 51: FE2 Module LEDs Functional status LEDs Interface status LEDs Understanding Status LEDs to Troubleshoot...
Page 122: Led Activity
ERX 7.0.x Hardware Guide Figure 52: E3 and T3 Module LEDs Functional status LEDs Interface status LEDs LED Activity When the system boots, it runs a series of tests for each module installed in the system, and the LEDs display various configurations. Refer to tables Table 12 and Table 13 to understand normal and abnormal LED activity.
Page 123 If you replaced the line module or if there was a hardware failure, the system should automatically reset the module. If condition persists, contact Juniper Networks Customer Service. FAN OK does not light Fan is not working properly or Contact Juniper Networks Customer has slowed down.
Page 124 Ethernet connection is down. Check that Ethernet cables are properly connected to both the Ethernet port and the appropriate network device. Contact Juniper Networks Customer Service. RED ALM System does not recognize a Check that all cables are firmly port connection.
Page 125: Redundancy Status
Troubleshooting Redundancy Status You can determine the redundancy state of line modules by examining the online and redundant status LEDs (ERX-7xx/14xx models only). See Table 14. NOTE: The REDUNDANT LED on the cOCx/STMx, FE-8, GE/FE, HSSI, and OCx/STMx modules is nonfunctional. Table 14: Redundancy Status of a Line Module ONLINE LED REDUNDANT LED...
Page 126: Resetting Line Modules And Srp Modules
ERX 7.0.x Hardware Guide Table 15: Troubleshooting High-Temperature Conditions (continued) Cause of High Operating Temperature Symptoms Resolution Cooling fan failure FAN OK LED on SRP module is Replace fan tray (see “Maintaining not illuminated. E-series Routers” on page 81). FAN FAIL LED on SRP module is illuminated.
Page 127: Fixing Double-Bit Errors
SRP module after you reboot, or if the FAIL LED on the SRP module stays on during rebooting, the SDRAM is permanently damaged and needs replacing. In this event, call Juniper Networks Customer Service to arrange for repair.
Page 128 ERX 7.0.x Hardware Guide Double-Bit Errors on SRP Modules...
Page 129: System Specifications
Chapter 10 System Specifications This chapter lists the system specifications, requirements, and certifications for E-series routers. ERX-14xx Models Specifications on page 113 ERX-7xx Models Specifications on page 116 ERX-310 Router Specifications on page 119 ERX-14xx Models Specifications Table 16: ERX-14xx Models Specifications Category Specification Weight...
Page 130 ERX 7.0.x Hardware Guide Table 16: ERX-14xx Models Specifications (continued) Category Specification Power 2400 W maximum Redundancy (input power) 2 independent line feeds Space Requirements 3 feet (90 cm) behind router or rack No space requirements for sides of units or rack Do not block air vents on front or back of the router Airflow An integral air plenum directs router’s exhaust air...
Page 131 System Specifications Table 16: ERX-14xx Models Specifications (continued) Category Specification Electromagnetic Emissions Agency Certification AS/NZS 3548:1995 (CISPR 22 Class A) EMC Directive (89/336/EEC) EN55022 Class A (CISPR-22 Class A) EN55024, Annex C for WAN Equipment Performance Criteria A, B, and C ETSI 300-386, Telecommunication Network Equipment;...
Page 132: Erx-7Xx Models Specifications
ERX 7.0.x Hardware Guide ERX-7xx Models Specifications Table 17: ERX-7xx Models Specifications Category Specification Weight Weights are approximate. Chassis only 22 lb (9.9 kg) Chassis fully configured 46 lb (20.7 kg) Dimensions 10.5 (H) x 19 (W) x 16 (D) inches; 26.67 x 48.26 x 40.64 cm Environmental Requirements NEBS GR-63-CORE compliant Long term: 41°...
Page 133 System Specifications Table 17: ERX-7xx Models Specifications (continued) Category Specification Safety Agency Certification AS/NZS 60950:2000 Safety of Information Technology Equipment CAN/CSA-C22.2, No. 60950-1–03, First Edition, Information Technology Equipment - Safety - Part 1: General Requirements EN60825-1, Safety of Laser Products - Part 1: Equipment Class, Requirements, and User’s Guide (2001) EN 60950-1:2001, First Edition, Information...
Page 134 ERX 7.0.x Hardware Guide Table 17: ERX-7xx Models Specifications (continued) Category Specification Electromagnetic Emissions Agency Certification AS/NZS 3548:1995 (CISPR 22 Class A) EMC Directive (89/336/EEC) EN55022 Class A (CISPR-22 Class A) EN55024, Annex C for WAN Equipment Performance Criteria A, B, and C ETSI 300-386, Telecommunication Network Equipment;...
Page 135: Erx-310 Router Specifications
System Specifications ERX-310 Router Specifications Table 18: ERX-310 Router Specifications Category Specification Weight: DC model Weights are approximate. Chassis only 25.5 lb (11.57 kg) Chassis, fully configured 36 lb (16.33 kg) Weight: AC model Weights are approximate. Chassis with single power supply 27.5 lb (12.47 kg) Chassis with dual power supply 31.5 lb (14.29 kg)
Page 136 ERX 7.0.x Hardware Guide Table 18: ERX-310 Router Specifications (continued) Category Specification Space Requirements 3 feet (90 cm) behind router or rack Do not block air vents on sides of the router. Do not place equipment that exhausts hot air to left on the right of the router.
Page 137 System Specifications Table 18: ERX-310 Router Specifications (continued) Category Specification Electromagnetic Emissions Agency Certification AS/NZS 3548:1995 (CISPR 22 Class A) EMC Directive (89/336/EEC) EN55022 Class A (CISPR-22 Class A) EN55024, Annex C for WAN Equipment Performance Criteria A, B, and C ETSI 300-386, Telecommunication Network Equipment;...
Page 138 ERX 7.0.x Hardware Guide ERX-310 Router Specifications...
Page 139: Appendixes
Part 2 Appendixes Installation Guidelines and Requirements on page 125 Cable Pinouts on page 137 Customer Support on page 145 Declaration of Conformity on page 151 Appendixes...
Page 140 Appendixes...
Page 141: Appendix A Installation Guidelines And Requirements
Appendix A Installation Guidelines and Requirements This chapter reviews preinstallation considerations such as electrical, environmental, and safety compliances for E-series routers. For complete system specifications, refer to “System Specifications” on page 113. This chapter contains the following sections: Your Preinstallation Responsibilities on page 125 Environmental Requirements on page 126 Regulatory Compliances on page 126 Safety Guidelines on page 126...
Page 142: Environmental Requirements
ERX 7.0.x Hardware Guide Environmental Requirements Refer to “System Specifications” on page 113 for complete environmental specifications. Choose a location for the router that is dry, relatively dust free, well ventilated, and air conditioned. If you install equipment in a rack, be sure that the floor is capable of supporting the combined weight of the rack and the installed equipment.
Page 143 Installation Guidelines and Requirements WARNING: Do not insert any metal object, such as a screwdriver, into an open slot or the backplane. Doing so may cause electric shock and serious burns. WARNING: Three people are required to install the E-series router in a rack: two to lift the system into position and one to screw it to the rack.
Page 144: Power Cord Warnings (Ac Model)
ERX 7.0.x Hardware Guide ERX-310 Power Cord Warnings (AC Model) WARNING: This unit has more than one power-supply cord. Disconnect 2 power cords BEFORE servicing to avoid electric shock. Denne enhed har mere end een strømfordelingsledning. Fjern ledning(er) nummer 2 FØR eftersyn for at undgå...
Page 145 Installation Guidelines and Requirements Figure 53: E-series Routers Installed in a Rack Equipment Rack Requirements...
Page 146: Mechanical Requirements
A fully loaded rack with three ERX-14xx models must structurally support 300 pounds (136 kilograms). Optional mounting kits are available for 19-inch and 23-inch rack mounting (mid- and front-chassis mounting). Contact your Juniper Networks sales representative for more information. Space Requirements...
Page 147: Cabling Recommendations
Installation Guidelines and Requirements WARNING: To maintain airflow requirements, a plenum must be installed above ERX-14xx models before any other piece of equipment is installed above the router. Figure 54: Airflow for E-series Routers Cabling Recommendations You may want to consult the document GR-63 (LSSGR, FD-15): Network Equipment Building System (NEBS) Requirements: Physical Protection, Issue 1, October 1995 for additional cable recommendations.
Page 148: Hardware Compliance
ERX 7.0.x Hardware Guide Comply with the following recommendations: Use only shielded cables. Ensure that cable distance and rate limits meet IEEE-recommended maximum speeds and distances for signaling purposes. For information about attenuation and power loss in optical fiber cables see: ANSI T1.646a-1997 Telecommunications –...
Page 149: Fcc Requirements For Consumer Products
Installation Guidelines and Requirements Reference: CFR 47, Part 15J, Sect 15.105 April 18, 1989 Caution: Changes or Modifications to this equipment not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC Requirements For Consumer Products This equipment complies with FCC rules, Part 68.
Page 150: Avis Cs-03 D'industrie Canada
ERX 7.0.x Hardware Guide guarantee the equipment will operate to the user’s satisfaction. Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. The equipment must also be installed using and acceptable method of connection. The customer should be aware that compliance with the above conditions may not prevent degradation of service in some situations.
Page 151: D.o.c. Explanatory Notes: Equipment Attachment Limitations
Installation Guidelines and Requirements Avis:Veuillez prendre note que pour tout appareillage supportant des lignes de type “loopstart,” l’indice d’équivalence de la sonnerie (IES) assigné à chaque dispositif terminal indique le nombre maximal de terminaux qui peuvent être raccordés à une interface. La terminaison d’une interface téléphonique peut consister en une combinaison de quelques dispositifs, à...
Page 152: Ec Declaration Of Conformity
ERX 7.0.x Hardware Guide Les réparations de l’appareillage certifié devraient être confiées à un service d’entretien canadien désigné par le fournisseur. En cas de réparation ou de modification effectuées par l’utilisateur ou de mauvais fonctionnement de l’appareillage, le service de télécommunications peut demander le débranchment de l’appareillage.
Page 153: Appendix B Cable Pinouts
Appendix B Cable Pinouts This appendix lists the cables and connector pinout assignments for the cables used with the ERX-7xx models and ERX-14xx models. It contains the following sections: SRP I/O Module on page 137 CT1 and CE1 I/O Modules on page 140 SRP I/O Module The SRP I/O module provides two management ports.
Page 154 ERX 7.0.x Hardware Guide Figure 55: SRP I/O Module Serial Port 10/100 BASE T PIN 1 RS-232 PIN 9 DB-9 Table 19 lists the pinout for the serial cable’s RS-232 connector. Table 19: SRP I/O Module—RS-232 Serial Connector Pinout Signal Once you have configured an IP address on the system, you can connect using a host running Telnet over the 10/100Base-T Ethernet port on the SRP I/O module.
Page 155 Cable Pinouts Figure 56: SRP I/O Module Ethernet Port PIN 8 PIN 1 PIN 8 10/100 BASE T RJ-45 PIN 1 RS-232 Table 20 lists the pinouts for the Ethernet cable’s RJ-45 connector. Table 20: SRP I/O Module—RJ-45 Connector Pinout Signal TX + TX –...
Page 156: Ct1 And Ce1 I/O Modules
ERX 7.0.x Hardware Guide Table 21: DB-9—RJ-45 Crossover Adapter Pinout DB-9 Pin Signal RJ-45 Pin no connect Table 22 lists the pinout for the straight-through adapter. Table 22: DB-9—RJ-45 Straight-Through Adapter Pinout RS-232 Signal Ethernet Signal DB-9 Pin Name RJ-45 Pin Name TX + TX –...
Page 157 Cable Pinouts Figure 57: CT1 I/O Module Ports CT-1 PIN 8 Port 0 PIN 1 Port 1 Port 2 Port 3 Table 23 lists the pinout for the CT1/CE1 connector. Table 23: CT1/CE1 I/O Module—RJ-48C Connector Pinout Signal RX Ring RX Tip no connect TX Ring...
Page 158 ERX 7.0.x Hardware Guide Figure 58: CE1 I/O Module with Telco Connectors PIN 26 PIN 1 PIN 25 PIN 50 Figure 59 shows the location of the 20 pairs of BNC connectors on a balun panel. The cables from the CE1 I/O module are plugged into the two 50-pin Telco connectors on the other side of the panel.
Page 159 Cable Pinouts Signal Signal Port 2 TX TIP Port 2 TX RING Port 3 RX TIP Port 3 RX RING Port 3 TX TIP Port 3 TX RING Port 4 RX TIP Port 4 RX RING Port 4 TX TIP Port 4 TX RING Port 5 RX TIP Port 5 RX RING...
Page 160 ERX 7.0.x Hardware Guide Signal Signal Port 16 TX TIP Port 16 TX RING Port 17 RX TIP Port 17 RX RING Port 17 TX TIP Port 17 TX RING Port 18 RX TIP Port 18 RX RING Port 18 TX TIP Port 18 TX RING Port 19 RX TIP Port 19 RX RING...
Page 161: Customer Support
Appendix C Customer Support See the Juniper Networks Web site for complete customer service information: http://www.juniper.net/support/guidelines.html This appendix contains the following sections: Contacting Customer Support on page 145 Return Procedure on page 145 Locating Component Serial Numbers on page 146...
Page 162: Locating Component Serial Numbers
ERX 7.0.x Hardware Guide Obtain a Return Materials Authorization (RMA) number from the Juniper Networks Technical Assistance Center (JTAC). See “Information You Might Need to Supply to JTAC” on page 147. Provide the following information in your e-mail message or during the...
Page 163: Information You Might Need To Supply To Jtac
Customer Support Figure 60: Representative Module Serial Number ID Label SRP I/O P/C: SRP_I/O Serial number ASY: xxx-xxxxx-xx ID label S/N: xxxxxxxxxx Ejector Information You Might Need to Supply to JTAC When requesting technical support from the JTAC by phone, be prepared to provide the following information: Priority level Indication of what activity was being performed on the router when the...
Page 164: Tools And Parts Required
Wire cutters Returning Products for Repair or Replacement In the event of a hardware failure, please contact Juniper Networks to obtain a Return Material Authorization (RMA) number. This number is necessary to ensure proper tracking and handling of returned material at the factory. Do not return any hardware until you have received an RMA.
Page 165 Customer Support To pack the chassis for shipment, follow these steps: Ground yourself by using an antistatic wrist strap or other device. Issue the proper shutdown commands to halt your system. Switch all power switches to the OFF position. Remove all cables from the chassis. Remove all major components from the chassis, including line modules, I/O modules, fan trays, and cable management systems.
Page 166 ERX 7.0.x Hardware Guide Returning Products for Repair or Replacement...
Page 167: Appendix D Declaration Of Conformity
Declaration of Conformity Declaration of Conformity on page 151 Declaration of Conformity Declaration of Conformity according to ISO/IEC Guide 22 and EN4514 Manufacturer’s Name: Juniper Networks, Inc. Manufacturer’s Address: Juniper Networks, Inc. 10 Technology Park Drive Westford, Massachusetts 01886 USA...
Page 168 ERX 7.0.x Hardware Guide Declaration of Conformity...
Page 169: Index
Part 3 Index Index...
Page 170 Index...
Page 171: Index
Index Symbols certification ........113, 116, 119 circulation, air.
Page 172 ERX 7.0.x Hardware Guide redundancy ......... .21 E-series models .
Page 173 Index normal activity........106 redundancy status .
Page 174 ERX 7.0.x Hardware Guide redundancy dimensions....... 113, 116, 119 SRP modules.........14 distribution rack .
Page 175 Index of rack........126, 130 ventilation.
