Depth Output - Simrad ES70 - REFERENCE MANUAL REV A Reference Manual

• : This is the Internet Protocol (IP) address of the local Ethernet
Local IP Address
interface board. In most cases, each Ethernet board has a unique IP address, even
when an interface board supports multiple sockets. If you have more than one
interface board, you are provided with a list of the available addresses.
• : Specify local network port. The ES70 uses this network port to transmit
Remote port
information. The application on the remote computer will "listen" to this port number.
•
Remote IP Address
If the data communication is set up to receive data only, this parameter is not required.
If you wish to set up an output for broadcast, define IP address
This is the default setting.
If you set the
Communication Mode
address manually.
•
Communication mode
Related topics
• EK500 Datagram on page 181
• I/O Setup on page 150

Depth Output

The dialog is opened from the
Annotation
Purpose
The dialog is used to set up the output of depth data from the ES70 to a
Depth Output
dedicated communication port on a specified format.
Description
The ES70 will output the current depth on several NMEA datagram formats. This dialog
allows you to define which port (serial or Ethernet) to use for such output, and which
format to use.
Parameters
• : Select which serial or Ethernet port to use for this communication.
Port
338106/A
: Select the Internet Protocol (IP) address for the remote computer.
to Point-to-Point, you need to enter the remote IP
: Choose Broadcast or Point-to-Point.
Annotation
Functions and dialogs
255.255.255.255
button on the menu.
Setup
.
147
