Simrad ES70
Parameters
•
Start Relative Bottom
is bottom related.
The start depth for the echogram shown on the display is defined by the
parameter on the
Main
→ Start Range on page 114
→ Echogram on page 158
• : This parameter controls the depth range.
Range
The range for the echogram shown on the display is defined by the
on the menu.
Main
→ Range on page 113
• : Check this box to apply the new range setting to all current echograms
Apply to all
of the same type.
Example: If you have selected a bottom echogram when you changed the range
setting, the setting will also be applied to all the other bottom echograms. A similar
functionality applies to the other echogram types.
Related topics
• Range on page 113
• Start Range on page 114
• Echogram on page 158
• EK500 Datagram on page 181

Surface Range

The dialog is opened from the
Surface Range
dialog.
Datagram
Purpose
This dialog is used to specify the vertical depth range for surface related echogram data
exported to peripheral devices, or saved to file.
184
: This parameter controls the start depth when the echogram
menu. The echogram type is selected in the
button in the
Surface Range
Start Range
dialog.
Echogram
parameters
Range
EK500
338106/A
