6 Sett the transducer(s) to None, and click
7 Click
Change IP Address
Note
If you have two Ethernet cables connected to your computer, you may need to
disconnect the Ethernet cable to the ship's network before the
is available.
8 Enter a new IP address
Tip
Change only the last digit in the IP address.
If you do have a keyboard connected to your ES70 system, click the
button at the bottom of the dialog to open an on-screen keyboard.
9 Click to save the current settings and close the dialog.
OK
10 In the
Transceiver Installation
transceiver has changed.
11 Install the transducers for the channel with the new IP address.
Note
Make sure that you choose the correct transducer(s)!
12 Click to save the current settings and close the dialog.
OK

How to install and upgrade the software

The ES70 is initially delivered with all necessary software installed and configured.
Software upgrades are useful if your ES70 fails, and you suspect a software error. An
upgrade is also required whenever the ES70 software is modified.
To check which software version you have, observe the
menu.
Display
→ About on page 133
The computer will automatically detect the insertion of the CD-ROM and open the
installation program's start-up dialog. If this is not the case, you must manually run the
program on the CD-ROM's root directory.
Setup.exe
When the ES70software is upgraded, the software will automatically detect the presence
of transceiver(s), but you will need to check that the correct transducer(s) are enabled.
Whenever new software is installed, you will also need to redefine all serial lines,
transducer(s) and transceiver(s).
338106/A
Apply
to open the
IP Address
dialog, observe that the IP address for the chosen
Operational procedures
.
dialog.
Change IP Address
dialog opened from the
About
Keyboard
