How To Establish Vertical Markers - Simrad ES70 - REFERENCE MANUAL REV A Reference Manual

Simrad ES70
2 Click
Echogram
→ Echogram on page 158
3 On the tab, observe the various markers that can be enabled.
Lines
• Bottom Line
• White Line
• Hardness Line
• Trawl Lines
• Variable Depth line
• Range Other lines
• Biomass line
• Scale lines
→ Lines, markers and annotations in the echograms on page 47
→ Echogram; Lines tab on page 159
4 Enable the lines you wish to see.
Note that the White Line and the Hardness Line can not be used simultaneously.
5 Click to save the current settings and close the dialog.
OK

How to establish vertical markers

A range of vertical markers can be enabled or disabled.
1 Click the
Active
2 Click
Echogram
→ Echogram on page 158
3 On the tab, observe the various vertical markers that can be enabled.
Lines
• Time
• Distance
• Annotations
The annotations are controlled on the
annotations on the echogram, you must enable them in the
→ Lines, markers and annotations in the echograms on page 47
→ Echogram; Lines tab on page 159
→ Annotations on page 137
4 Enable the vertical markers you wish to see.
5 Click to save the current settings and close the dialog.
OK
72
to open the
Echogram
icon under the
Main
to open the
Echogram
dialog.
menu to open the
Active
dialog.
dialog, but to place the
Annotation
sub-menu.
dialog.
Echogram
338106/A
