LAN Port Setup

The dialog is opened from the
LAN Port Setup
dialogs:
• Annotations on page 137
• Navigation on page 140
• Depth Output on page 147
• I/O Setup on page 150
Purpose
The
LAN Port Setup
communication with external sensors (measuring devices) or peripheral systems.
338106/A
dialog allows you to define the parameters for Ethernet
Description
Ethernet (LAN) communication is an efficient way
to connect to external sensors, such as a global
positioning system (GPS) to receive navigational
data. In order for this communication to work, it
must be set up properly.
Functions and dialogs
button in the following
LAN Port Setup
