Zoom information pane

The information pane allows you to zoom in on a chosen area on the current
Zoom
echogram.
To open this information pane, click the
Figure 10 Zoom example
338106/A
Once the information pane is opened, the
Zoom
zoomed area is visible as a dotted rectangle on the
echogram. You can change this zoomed area to any
size and shape, the echoes inside the zoomed area will
always be shown in the
: When the rectangular zoomed
Area Fixed To Vessel
area is established, it can either follow the echogram
while it moves towards the left, or it can stay put.
When
Area Fixed To Vessel
will be permanently positioned on the echogram. The
echoes will then run through the area, and thus also
through the information pane.
Zoom
icon on the
Zoom
information pane
A
Zoom
Zoomed area rectangle
B
In this example, the zoomed area rectangle
is positioned directly above the
information pane. If you click on any of the
four corners of the rectangle, you can drag it
to any size and shape.
Display views
information pane.
Zoom
is active, the zoomed area
.
Title Bar
Zoom
57
