Simrad ES70
→ How to establish horizontal markers on page 71
→ Echogram; Lines tab on page 159
Vertical ticks
When enabled in the
echogram.
• : This option places a short vertical line is drawn in the upper part of the
Time
echogram once every specified number of minutes.
• : This option inserts a short vertical line is drawn in the upper part of the
Distance
echogram once every specified number of nautical miles.
→ Echogram; Lines tab on page 159
Annotations
Annotations may be added to the echogram to pinpoint special echoes, special events,
etc. can be entered manually using the Annotation dialog, or they can be
Annotation
imported from peripheral devices.
In order to see the annotations on the echogram, they must be enabled in the
dialog.
→ Annotations on page 137
→ Echogram; Lines tab on page 159

Information panes

The Simrad ES70 offers several information panes to provide additional and detailed
data from the echogram. The panes are opened and closed using the pane buttons on
the .
Title Bar
Note
Some of the information panes are optional. They are thus not available for use unless a
licence code is available. In order to obtain a licence, consult your local dealer.

About information panes

In order to open an information pane, you must first click in an echogram presentation to
make it "active". By doing this you select frequency channel (transducer). In most cases,
the data in the information pane you open will only be valid for the selected echogram.
50
dialog, this function places vertical markers on the
Echogram
Echogram
