Logo And Product Name; Operation Buttons - Simrad ES70 - REFERENCE MANUAL REV A Reference Manual

• : These buttons are used to control basic functions such as screen captures,
Function
help, menu appearance
→ Function buttons on page 42

Logo and product name

The Simrad logo and the product name (ES70) is shown.
Double-click the Simrad logo to reduce the size of the ES70 presentation. Double-click
one more time to restore the original size.

Operation buttons

Menu button
Click once on the
Menu
again. When the menu is hidden, it will temporarily be shown on the left and right hand
side of the display if you move the cursor to that position.
→ Main menu on page 43
→ The menu system on page 102
Screen capture button
Click this button once to create a screen capture of the current echogram presentation. To
view the recorded image, click
→ How to save an echogram on page 64
→ Screen captures on page 59
Record button
Click this button to start and stop recording.
338106/A
button to hide the menu, and one more time to bring it back
Screen Capture
on the to open the image browser.
Taskbar
