Simrad ES70 - REFERENCE MANUAL REV A Reference Manual page 67

How to retrieve a saved echogram
1 On the , click
Taskbar
Observe that the built-in image browser starts. All the currently saved echogram
images are shown as miniatures.
→ Operation buttons on page 37
Double-click on the miniature you wish to see.
2
3 Click
Return To Browser
How to copy and delete echogram files
1 On the , click
Taskbar
Observe that the built-in image browser starts. All the currently saved echogram
images are shown as miniatures.
→ Operation buttons on page 37
2 In the image browser, click
To copy a file:
3
a Connect a USB memory device to one of the computer's USB sockets.
b Select the file.
Right-click to open the short-cut menu.
c
d Click
Send to
4 To delete a file:
Select the file.
a
b Right-click to open the short-cut menu.
c Click
Delete
To print a file:
5
a Select the file.
b Right-click to open the short-cut menu.
Click .
c
Print
Note that this function will send the image to the default printer using default print
parameters. If you wish to apply more control to the printing process, you must copy
the echogram image to another computer, and open it with a suitable editor.
338106/A
Screen Captures
to close the image.
Screen Captures
Open Image Folder
and select the memory device.
.
.
.
.
Operational procedures
65
