Ping-Ping Filter

The function is opened from the
Ping-Ping Filter
menu.
Purpose
The reduces unwanted noise and echoes from the echogram presentation.
Ping-Ping Filter
Parameters
• : Choose one of the following settings:
Ping-Ping Filter
– : No filtering
Off
– : For the current echo pixel to be shown, the echo pixel from at least one of
2 of 3
the two previous pings must have a colour value different from the background.
– : For the current echo pixel to be shown, the echo pixel from the previous
2 of 2
ping must have a colour value different from the background to be shown.
– : For the current echo pixel to be shown, the echo pixel from the two previous
3 of 3
pings must have a colour value different from the background to be shown.
• : Click this button if you wish to implement your changes to all the
Apply to all
echograms presently in use on the ES70.
Related topics
• How to remove interference and vessel's own noise from the echograms on page 74

Bottom Gain

The function is opened from the
Bottom Gain
338106/A
Ping-Ping Filter
Description
The filter has three different strengths. As the
ping-to-ping filter compares the echoes from the last
ES70, it will take this selected amounts of transmissions
("pings") to make a stable presentation when changing
most of the ES70 parameters. The filtering routine
takes the vessel's movements into consideration when
comparing the echoes from ping to ping. The filter
works by comparing each separate pixel colour from the
previous pings.
Bottom Gain
Functions and dialogs
button on the
Active
button on the menu.
Active
