Echogram Colours
– : Set the number of colours to use in the display presentations, 12
No of colours
or 64.
– : Select the desired colour scale to be used on the ES70 presentations.
Colour scale
Note that all colour scales require that the number of colours is set to 64.
The options are:
* Sonar Colours
* Echosounder Colours
* Grayscale
* BI500 Colours
The Echosounder Colours are based on the standard 12–colour scale, but additional
colours have been added between these to make smoother colour transitions.
Related topics
• Colour Scale information pane on page 53
• How to change the colour scale and presentation palette on page 69

Screen Brightness

The
Screen Brightness
the menu.
Display
Purpose
The purpose of the
Screen Brightness
off by the display.
Description
When the bridge is dark, the light emitted by the ES70 display can affect your night
vision. In order to compensate for this, you can reduce the intensity. The
allows you to reduce the this brightness, and hence make the display darker.
Brightness
Parameters
• : The intensity of light emitted by the display can be reduced from 100% to
Brightness
0% in steps of 10.
Related topics
• Colour Setup on page 125.
338106/A
:
function is available by clicking the
function is to adjust the intensity of the light given
Functions and dialogs
button on
Screen Brightness
Screen
127
