3 = coordinated universal time (UTC)
DHB
= time
4
hhmmss.ss
5 = transducer number
t
= echo sounder frequency in kHz
6
f,KHZ
7 = detected bottom depth in meters. Given as DBS (depth below surface),
x.x,M
assuming proper transducer draft has been entered.
8 = bottom surface hardness in dB
y.y,DB
9 = relative biomass density in m²/nmi² (NASC) (s
z.z
NASC means Nautical Area Scattering Coefficient. This is the format (s
we provide the biomass data.
10 = spare for future expansions
spare1
11 = spare for future expansions
spare2
Related topics
• Depth Output on page 147
• Select Outputs on page 175
• I/O Setup on page 150

Sounder/TSS1 Motion protocol

This proprietary
Simrad Sounder/TSS1
heave, roll and pitch compensation. When you select this protocol, the number of sensor
variables is fixed, and there is no token associated with it. However, baud rate and output
rate may be adjusted to fit your needs. The format is based on ASCII characters, the
datagrams have fixed length, and it is terminated with a carriage return and line feed.
The definition of the attitude angles in this format is different from the Euler angles
definition used elsewhere. The difference appears in the roll angle, where:
Format
:aabbbb shhhhxsrrrr spppp<cr><lf>
Format description
1 = sway – two characters hex number with sway acceleration, in 0.03835 m/ss
aa
units
= heave – four characters hex number with heave acceleration, in 0.000625
2
bbbb
m/ss units
3 = a single character providing a "space" character if the value is positive, or a
s
"–" character if it is negative
338106/A
)
A
protocol may be the most common interface for
Telegram formats
m²/nmi²)
A
201
