Operational procedures

This chapter contains several operational procedures explaining how you can put your
ES70 Fish finding echo sounder to use.
Note
These procedures assume that you are fairly familiar with the Microsoft Windows
operating system. Phrases and terminology are consistent with the Microsoft style guide.
The procedures also assume that you operate the echo sounder with a mouse or trackball.
Topics
•
Getting started
– Power On/Off procedures on page 19
– How to choose operational mode on page 22
– How to check the transceiver and transducer settings on page 22
– How to check the bottom detector settings on page 23
– How to check the colour scale settings on page 24
– How to check the size distribution and fish position settings on page 24
– How to check the echogram settings on page 25
– How to check the range settings on page 27
•
Operation
– How to change the ping rate on page 63
– How to save an echogram on page 64
– How to save raw echogram data on page 66
– How to play back echogram sequences on page 67
•
Views
– How to change the size of the presentation fields on page 68
– How to select presentation layout on page 69
– How to change the colour scale and presentation palette on page 69
– How to change the number of colours in the echogram on page 70
