Parameters
• : Click to this option disable the ES70 operation. Neither transmission nor
Inactive
reception will take place.
When the ES70 has been disabled using this function, it will stop. The current
echogram is removed from the screen.
• : Click this option to enter normal operational mode.
Normal
If you wish to establish a passive system (transmission switched off, but normal
reception), click the
→ Normal Operation on page 121.
• : Click to this option to choose playback mode.
Replay
In order to select which recording to play back, click
dialog. See Replay File on page 177 for further information.
File
Related topics
• How to play back echogram sequences on page 67
• Normal Operation on page 121
• Replay File on page 177

Ping

The function is available by clicking the
Ping
Purpose
The purpose of the
Ping
into the water ("pinging").
118
Description
The ES70 will during normal operation display the echo
signal received at the transducer. Using this
function, it may also be set up to play back a previously
recorded echo signal. If you do not wish to use the
echo sounder for a short period, you can set the ES70
to inactive. Click the middle of the button to open the
sub-menu.
button, and select Passive mode in the dialog.
Normal Operation
function is to enable or disable the ES70 audio transmissions
Replay File
button on the
Ping Operation
Operation
to open the
Replay
menu.
