Simrad ES70
3
For the relevant transducer channel, set
→ About output power on page 207
4
Click
to save the current settings and close the dialog.
OK
Note
If you increase the output power, make sure that you do not choose more power than your
transducer can handle. With a correct setup with the transducer registered in the echo
sounder software you are safeguarded against this. However, if you use a third party
transducer that is not known by the echo sounder software, you may inflict permanent
damage if you increase the output to beyond the transducer's capabilities.

How to adjust the pulse duration

The length of your transmitted pulse is very important to how you can detect fish. A
short pulse duration gives you a very fine vertical resolution. This allows you to detect
scattered fish, and you can find those that move near the bottom. A long pulse duration
throws a lot more energy into the water, and the digital filters used by the receiver are
narrower. These filters will reduce the ES70's sensitivity for noise, but the length of the
transmitted pulse will give you stronger echoes. With the filters, a longer pulse duration
will provide longer range, but reduced vertical resolution.
1
Click the
Operation
Click
2
Normal Operation
→ Normal Operation on page 121
3
For the relevant transducer channel, set
For general use, we recommend that the pulse duration is set to Auto.
→ About pulse duration on page 207
Click
to save the current settings and close the dialog.
4
OK

Installation

These procedures explain how to install transceiver unit and new software versions. It
also explains how to set up the external motion sensor.

How to install a frequency channel

Click the
icon under the
1
Setup
82
Power [W]
icon under the
menu to open the
Main
to open the
Normal Operation
Pulse Length
menu to open the
Main
to requested value.
sub-menu.
Operation
dialog.
to requested value.
sub-menu.
Setup
338106/A
