2 Spin the scroll wheel in either direction to increase or decrease the parameter value.
3 Release the scroll wheel when the requested value is shown.
How to select a numerical parameter using the keyboard
1 Click the middle section of the button to open a text field.
2 Enter the numerical value into the text field.
If the numerical value exceeds the permitted range for the parameter, the frame in
the text field will be red. You will then not be able to enter the value.
3 Press the key.
Enter
How to select a parameter using a sub-menu
1 Click the middle section of the button to open a sub-menu, then click the requested
parameter value.
The chosen value is applied, and the sub-menu is automatically closed.
Whenever applicable, you can also access the sub-menu by clicking the left and
2
right side of the button, but this method will not show you the menu choices.
Click on the left side of the button to select a lower sub-menu choice.
a
Click on the right side of the button to select a higher sub-menu choice.
b
How to select parameters using a dialog
1 Click anywhere on the button to open a separate dialog.
