3.13.3 Avoiding Obstacles

Avoid obstacles by using the steering control lever.
Follow the steps below to steer the rotary disc pull-type around
an obstacle.
1. Activate steering control lever (A) to steer the rotary disc
pull-type into the desired path of travel.
Move the lever FORWARD to position (B) to steer the
rotary disc pull-type to the right.
Move the lever BACKWARD to position (C) to steer the
rotary disc pull-type to the left.
262634
OPERATION
Figure 3.62: Rotary Disc Pull-Type Steered around
Obstacle
B
Figure 3.63: Tractor Steering Control Lever
72
A
C
Revision A
