Table 3.4 Hydraulic System Hoses
System
Hose Identification
Red #1 - pressure
Lift (A) Blue #1 - return (only
with transport installed)
Swing/
Red #2 - pressure
Transport (B)
Blue #2 - return
Red #3 - pressure
7
Tilt (C)
Blue #3 - return
1. Connect the lift cylinder hose (red collar with #1) to the
tractor s hydraulic receptacle. Connect the second hose
(blue collar with #1) only when the transport is installed.
Refer to Table 3.5, page 55
functioning correctly.
2. Connect the two hitch swing cylinder hoses (collars with #2)
to the tractor hydraulic receptacles. Refer to Table
page 55 to confirm the system is functioning correctly.
3. For machines with a hydraulic center-link only, connect the
two tilt cylinder hoses (collars with #3) to the tractor
hydraulic receptacles. Refer to Table
confirm the system is functioning correctly.
7. Available with hydraulic tilt option installed.
262634
OPERATION
Tractor
Hydraulics
Control 1
Control 2
Control 3
to confirm the system is
3.6,
3.7, page 55 to
Figure 3.33: Hydraulic Connections
Table 3.5 Lift System
Control Lever
Position
Forward
Backward
Table 3.6 Hitch Swing and Transport System
Control Lever
Position
Forward
Backward
Table 3.7 Tilt System
Control Lever
Position
Forward
Backward
55
Rotary Disc
Cylinder
Pull-Type
Movement
Movement
Retract Lower
Extend Raise
Rotary Disc
Cylinder
Pull-Type
Movement
Direction
Right
Extend
Retract Left
Rotary Disc
Cylinder
Pull-Type
Movement
Movement
Retract Lower
Extend Raise
Revision A
A
B
C
