MacDon R1 Series Operator's Manual page 315

1. Lower the rotary disc pull-type fully.
2. Shut down the engine, and remove the key from the ignition.
3. Engage the lift cylinder lock-out valves. For instructions, refer to
4. Remove left and right driveshields (A). For instructions,
refer to Removing Driveshields, page
5. Open the cutterbar doors. For instructions, refer to
Opening Cutterbar Doors – North America, page 41
Opening Cutterbar Doors – Export, page
6. Check rotor fingers (A) for damage and replace any bent
fingers to prevent rotor imbalance.
262634
MAINTENANCE AND SERVICING
238.
Figure 4.287: Driveshields
3.3.1
or 3.3.2
42.
Figure 4.288: Cutterbar Doors
Figure 4.289: Rotor Fingers
297
3.1.1 Engaging Locks, page
A
35.
A
A
Revision A
