1. Release two lever clamps (A) (one shown) using a
screwdriver or similar prying tool.
2. Unhook safety chain (B) from hitch, and ensure that chain is
secured to the shield cone and metal plate.
3. Remove shield cone from metal plate (A) and slide cone
along driveshaft.

Installing Driveline Shield Cone

installing the driveline shield cone.
WARNING
Do NOT operate the machine without the driveline shield cones in place and the lever clamps securely fastened.
262634
MAINTENANCE AND SERVICING
Figure 4.179: Driveline Shield Cone and Lever Clamp
Figure 4.180: Driveline Shield Cone Removed from
Metal Plate
242
B
A
A
Revision A
