5.1.3 Driveline Extension Kit

Some tractor models using a two-point hitch may require a longer primary driveline than the factory-installed driveline on
R1 Series Rotary Disc Pull-Types. The Driveline Extension kit can be used to extend the primary driveline length by an
additional 152 mm (6 in.).
B6555 Full shaft for 1 3/8 in. tractor 1000 RPM PTO
Extended Length
B6556 Full shaft for 1 3/4 in. tractor 1000 RPM PTO
Extended Length

5.1.4 Tractor Utility Hitch Adapter

The Tractor Utility Hitch Adapter allows the rotary disc pull-type to connect to a tractor drawbar regardless of installed
hitch option (Tractor Two-Point Hitch Adapter or Tractor Drawbar Hitch Adapter).
The kit includes the transport hitch, attachment hardware, and
safety chain.
B5802
262634
OPTIONS AND ATTACHMENTS
Figure 5.3: Driveline (B6555 Shown, B6556 Similar)
Figure 5.4: Tractor Utility Hitch Adapter
