MacDon R1 Series Operator's Manual page 175

DANGER
Ensure that all bystanders have cleared the area.
WARNING
Disc blades have two sharp cutting edges that can cause serious injury. Exercise caution and wear gloves when working
with, or near, blades.
1. Position the rotary disc pull-type at an appropriate height for the task.
2. Shut down the engine, and remove the key from the ignition.
3. If the rotary disc pull-type is raised:
a. Place blocks under each end, or just inside each end, of the cutterbar.
b. Lower the rotary disc pull-type onto the blocks.
c. Shut down the engine, and remove the key from the ignition.
d. Close the lift cylinder lock-out valves. For instructions, refer to
4. Open the cutterbar doors. For instructions, refer to
Opening Cutterbar Doors – Export, page
5. Remove four nuts, bolts, and large washers (A) securing the
outboard curtain to the endsheet.
262634
MAINTENANCE AND SERVICING
3.3.1 Opening Cutterbar Doors – North America, page 41
42.
Figure 4.28: Left Endsheet
157
3.1.1 Engaging Locks, page
A
35.
or 3.3.2
Revision A
