MAINTENANCE AND SERVICING
A
B
C
Figure 4.15: Lubrication Locations (Every 100 Hours)
A - Check Plug - Cutterbar-Conditioner Drive Gearbox (T-Gearbox) 12 B - Bearing - Field Wheel (2 Places) 13
™
C - Bearing - Road Friendly Transport Option (2 Places)
12. Remove the check plug from the conditioner drive gearbox as shown and the check oil level.
13. Use high-temperature extreme-pressure (EP2) performance with 1% max molybdenum disulphide (NLGI grade 2)
lithium base.
