iC7-Automation Air-cooled Enclosed Drives
Operating Guide
Model code Frame
iC7-60EA3A05-588A
iC7-60EA3A05-658A AE11 + IE11
iC7-60EA3A05-730A
iC7-60EA3A05-820A
iC7-60EA3A05-880A
iC7-60EA3A05-1000 2xAE10 +
2xIE10
iC7-60EA3A05-1100
iC7-60EA3A05-1260 2xAE11 +
2xIE11
iC7-60EA3A05-1450
iC7-60EA3A05-1710
With the vertical PE busbar extension installed: 20 x Ø6.5 mm or 16 x Ø6.5 mm + 4 x Ø10.5mm
1

10.6 Fuses

10.6.1 List of Fuse Size Information

The fuse size tables for the air-cooled enclosed drives can be found with these links.
• 10.6.2 AC Fuses, 380–500 V AC
• 10.6.3 DC Fuses, 465–800 V DC
• 10.6.4 External Fuses on External Supply for input devices
10.6.2 AC Fuses, 380–500 V AC
Table 37: AC Fuses, 380–500 V AC
Model code Frame
iC7-60EA3N05-206A FE9
iC7-60EA3N05-245A
iC7-60EA3N05-302A
iC7-60EA3N05-385A
iC7-60EA3N05-480A FE10
iC7-60EA3N05-588A
iC7-60EA3A05-385A AE10 + IE10
iC7-60EA3A05-480A
iC7-60EA3A05-588A
100 | Danfoss A/S © 2023.09
I [A] Motor cable, Cable termina-
N
Cu tion, Panduit ter-
minal part num-
ber
531 3x 250 MCM LCAX250-12-X
603 3x 350 MCM LCAX350-12-6
672 4x 250 MCM LCAX250-12-X
746 4x 300 MCM LCAX300-12-6
838 4x 350 MCM LCAX350-12-6
940 6x 4/0 AWG LCAX4/0-12-X
1052 6x 250 MCM LCAX250-12-X
1174 6x 300 MCM LCAX300-12-6
1328 8x 250 MCM LCAX250-12-X
1603 8x 300 MCM LCAX300-12-6
Rated Number Fuse
current of fuses size
I [A]
L
206 3 00
245 3 00
302 3 00
385 3 00
480 3 1
588 3 1
385 3 33
480 3 33
588 3 33
Maximum Maximum
cable size number of
motor ca-
bles (bolt
size)
500 MCM 4 (M10)
500 MCM 4 (M10)
500 MCM 4 (M10)
500 MCM 4 (M10)
500 MCM 4 (M10)
500 MCM 8 (M10)
500 MCM 8 (M10)
500 MCM 8 (M10)
500 MCM 8 (M10)
500 MCM 8 (M10)
Part number Fuse U
[V]
170M2619 700
(2)
170M2620 700
(2)
170M2621 700
(2)
170M9007 550
(2)
170M4016 700
(2)
170M4017 700
(2)
PC33UD69V550TF 690
(3)
PC33UD69V700TF 690
(3)
PC33UD69V700TF 690
(3)
AQ330347384398en-000201 / 139Z8096
Specifications
Number of
grounding
holes on PE
busbar (hole
size [mm])
(1)
4 (Ø10.5)
4 (Ø10.5)
4 (Ø10.5)
4 (Ø10.5)
4 (Ø10.5)
8 (Ø10.5)
8 (Ø10.5)
8 (Ø10.5)
8 (Ø10.5)
8 (Ø10.5)
Fuse I I [A]
n n cp,mr
[A]
(1)
315 –
350 –
400 –
475 –
630 –
800 –
550 3288
700 4822
700 4822
