iC7-Automation Air-cooled Enclosed Drives
Operating Guide
1 Control compartment
2 Contactor
3 Main switch
4 AC fuses, 3 pcs
5 Motor fan control/supply terminals (+ICFI1-4), AUX
AC supply terminals (+IHAS)
6 PE busbar
7 Inlet air grill

3.8 Interior View of the Cabinet, AE11 + IE11

7
1
2
3
4
5
6
12
13
Illustration 4: Interior View of the Cabinet, AE11 + IE11
Danfoss A/S © 2023.09
8 Control cable grommet, top
9 DC fuses, 2 pcs, behind the touch protection plate
10 Motor terminals
11 Mains terminals
12 Control cable grommet, bottom
13 IP54 grommet for mains and motor cables (IEC)
8
9
10
11
14
Product Overview
AQ330347384398en-000201 / 139Z8096 | 17
