Danfoss iC7-60EA3N05-206A Operating Manual page 73

iC7-Automation Air-cooled Enclosed Drives
Operating Guide
568
(22.36)
120
C
368
(4.72)
(14.49)
2280
(89.76)
2405
(94.69)
608
(23.94)
657
(25.87)
D
Illustration 49: Dimensions of the Enclosed Drive, AE10, AE11, IE10, and IE11, in mm (in)
A View from the top
B View from the bottom
Danfoss A/S © 2023.09
A
W1 - 65 65 W2 - 65
(W1 - 2.56) (2.56) (W2 - 2.56)
Ø13
(Ø0.51)
W1 W2
W
B
W1 - 90 90 W2 - 90
(W1 - 3.54) (3.54) (W2 - 3.54)
W1 - 225 225 W2 - 225
(W1 - 8.86) (8.86) (W2 - 8.86)
DD
2303
(90.67)
2238
(88.11)
2202
(86.93)
200
(7.87)
211
(8.31)
W3
Ø13 x 23
(Ø0.51 x 0.91)
589
657
(23.19)
(25.87)
C IP54 hood
AQ330347384398en-000201 / 139Z8096 | 73
Specifications
W4
