7.5 I/O and Relay Option Connections
Illustration 27: I/O and Relay Option Terminal Block and Terminal Numbering
Table 13: I/O and Relay Option Signals
Terminal
Function
X13
I/O terminal
X51
Thermistor input
X101
Relay 1
X102
Relay 2
X103
Relay 3
Table 14: I/O Terminal Signals (X13)
Terminal
Function
Description
11
+24 V
Control voltage output.
out
24 V DC (-15...+20%)
12
+24 V
out
Maximum current 200 mA
Short-circuit protected
13
DI 1
Configurable digital input, galvanically isolated.
24 V DC, 0 < 5 V, 1 > 15 V.
14
DI 2
Input load 7.5 mA constant current + 10 kΩ resistive load, maximum pulse frequency 100 kHz.
15
DI 3
16
DI 4
17
DI 5
18
DI 6
Danfoss A/S © 2023.09
X13
11
12
13
14
15
16
17
18
19
20
21
22
23
24
31
32
33
34
35
36
37
38
X51
71
72
X101
1
2
3
X102
4
5
6
X103
7
8
Connector type
2 x 11 spring force connector 0.2–1.5 mm
1 x 2 spring force connector 0.25–2.5 mm
1 x 3 spring force connector 0.25–2.5 mm
1 x 3 spring force connector 0.25–2.5 mm
1 x 2 spring force connector 0.25–2.5 mm
Control and Option Installation
2
2
2
2
2
