Illustration 40: Example of Installing the Control Cables on Terminals Blocks
1
Option board
2
Cable clamp
3
Cable duct
2.
Strip the control cables. Attach the control cables to the cable clamps on the control compartment.
60 | Danfoss A/S © 2023.09
Control and Option Installation
4
Terminal block
5
Guidance for the control cable
AQ330347384398en-000201 / 139Z8096
