iC7-Automation Air-cooled Enclosed Drives
Operating Guide
Model code Frame
iC7-60EA3A05-588A
iC7-60EA3A05-658A AE11 + IE11
iC7-60EA3A05-730A
iC7-60EA3A05-820A
iC7-60EA3A05-880A
iC7-60EA3A05-1000 2 x AE10 + 2
x IE10
iC7-60EA3A05-1100
iC7-60EA3A05-1260 2 x AE11 + 2
x IE11
iC7-60EA3A05-1450
iC7-60EA3A05-1710
With the vertical PE busbar extension installed: 20 x Ø6.5 mm or 16 x Ø6.5 mm + 4 x Ø10.5mm
1
10.5.4 Mains Cable Size Recommendation, UL 480 V
Table 35: Mains Cable Size Recommendation, UL 480 V
Model code Frame
iC7-60EA3N05-206A FE9
iC7-60EA3N05-245A
iC7-60EA3N05-302A
98 | Danfoss A/S © 2023.09
2
I [A] Cable [mm ]
N
601
Cu 2 x (3x150+70)
Al 2 x (3x185+57 Cu)
672
Cu 2 x (3x185+95)
Al 3 x (3x150+70 Cu)
746
Cu 3 x (3x150+70)
Al 4 x (3x120+41 Cu)
838
Cu 3 x (3x150+70)
Al 4 x (3x150+70 Cu)
899
Cu 4 x (3x120+70)
Al 4 x (3x150+70 Cu)
1021
Cu 4 x (3x150+70)
6 x (3x95+29 Cu)
1123
Cu 4 x (3x185+95)
Al 6 x (3x120+41 Cu)
1287
Cu 6 x (3x120+70)
Al 6 x (3x150+70 Cu)
1481
Cu 6 x (3x150+70)
Al 6 x (3x185+57 Cu)
1746
Cu 6 x (3x185+95)
Al 8 x (3x150+70 Cu)
I [A] Mains cable Cable termina-
N
Cu tion, Panduit ter-
minal part num-
ber
206 2 x 300 MCM LCAX300-12-6
245 2 x 300 MCM LCAX300-12-6
302 2 x 300 MCM LCAX300-12-6
Maximum Maxi- Bolt
cable size mum size
2
[mm ] num-
(1)
ber of
motor
cables
240 Cu/Al 4 M10
240 Cu/Al 4 M10
240 Cu/Al 4 M10
240 Cu/Al 4 M10
240 Cu/Al 4 M10
240 Cu/Al 8 M10
240 Cu/Al 8 M10
240 Cu/Al 8 M10
240 Cu/Al 8 M10
240 Cu/Al 8 M10
Maximum
cable size
300 MCM
300 MCM
300 MCM
AQ330347384398en-000201 / 139Z8096
Specifications
Number of Hole size
grounding of the
holes on grounding
PE busbar terminal
[mm]
4 Ø10.5
4 Ø10.5
4 Ø10.5
4 Ø10.5
4 Ø10.5
8 Ø10.5
8 Ø10.5
8 Ø10.5
8 Ø10.5
8 Ø10.5
Maximum Number of
number of grounding
mains ca- holes on PE
bles (hole busbar (hole
(1)
size of the size [mm])
mains termi-
nal [mm])
2 (Ø10.5) 2 (Ø10.5)
2 (Ø10.5) 2 (Ø10.5)
2 (Ø10.5) 2 (Ø10.5)
