iC7-Automation Air-cooled Enclosed Drives
Operating Guide
Table 49: Current Ratings for Low-harmonic AFE, 500 V AC
Model code Frame
iC7-60EA3H05-385A AE10+IE10
iC7-60EA3H05-480A AE10+IE10
iC7-60EA3H05-588A AE10+IE10
iC7-60EA3H05-658A AE11+IE11
iC7-60EA3H05-730A AE11+IE11
iC7-60EA3H05-820A AE11+IE11
iC7-60EA3H05-880A AE11+IE11
iC7-60EA3H05-1000 2 x AE10+2 x IE10
iC7-60EA3H05-1100 2 x AE10+2 x IE10
iC7-60EA3H05-1260 2 x AE11+2 x IE11
iC7-60EA3H05-1450 2 x AE11+2 x IE11
iC7-60EA3H05-1710 2 x AE11+2 x IE11

10.8 Technical Data

10.8.1 Mains Connections

Table 50: Mains Connections
Item
Nominal AC voltage
Mains network
Mains frequency
Voltage imbalance
Short-circuit current rating, with the specified fuses or
circuit-breakers
True power factor (λ)
Displacement power factor (DPF)
Switching on input supply from a discharged drive
Overvoltage category
Danfoss A/S © 2023.09
Nominal ratings
I [A] I [A] I [A]
N-in N peak
322 372 510
406 466 619
457 531 776
518 603 833
583 672 930
647 746 1031
725 838 1158
815 940 1299
919 1052 1454
1034 1174 1632
1164 1328 1836
1422 1603 2227
Technical data
Voltage class 5: 3 x 380...500 V AC ±10%, -15% at reduced power
TN-S, TN-C, IT and TT. (Supply voltage limited to 500 V AC for corner-
grounded networks.)
45...66 Hz
3% of rated voltage
The maximum short circuit current I
≥ 0.9 nominal at rated load
AFE: 1
6-pulse: 0.97
FE09–FE10: Maximum 1 time/2 minutes
Category III
Low overload High overload
I [A] I [A] I [A] I
L-in L H-in H
315 364 254 300
397 456 315 364
447 520 397 456
506 590 399 490
570 658 450 547
633 730 506 606
709 820 570 681
797 920 633 764
899 1030 709 855
1012 1150 797 960
1139 1300 899 1080
1392 1570 1012 1310
≤ 65 kA
cc
AQ330347384398en-000201 / 139Z8096 | 107
Specifications
Typical motor power,
500 V AC
[A] P [kW] P [kW]
L H
250 200
315 250
355 315
400 315
450 355
500 400
560 450
630 500
710 560
800 630
900 710
1100 800
