iC7-Automation Air-cooled Enclosed Drives
Operating Guide
Abbrevia- Description
tion
I
Nominal current with high overload (150%). Allows a +50% load variation for 1 minute every 5 minutes.
H
I Start current. Available for 3 s at start, then as long as the enclosed drive temperature allows. Relevant for inverter
peak
modules.
P Output power at low overload
L
P Output power at high overload
H

10.7.2 Current Ratings for 6-pulse Enclosed Drives, FE9 and FE10, 400 V AC

Current ratings
Table 41: Current Ratings for 6-pulse Enclosed Drives, FE9 and FE10, 400 V AC
Model code Frame
iC7-60EA3N05-206A FE9
iC7-60EA3N05-245A FE9
iC7-60EA3N05-302A FE9
iC7-60EA3N05-385A FE9
iC7-60EA3N05-480A FE10
iC7-60EA3N05-588A FE10

10.7.3 Current Ratings for 6-pulse Enclosed Drives, FE9 and FE10, UL, 460 V AC

Table 42: Current Ratings for 6-pulse Enclosed Drives, FE9 and FE10, UL, 460 V AC
Model code Frame
iC7-60EA3N05-206A FE9
iC7-60EA3N05-245A FE9
iC7-60EA3N05-302A FE9
iC7-60EA3N05-385A FE9
iC7-60EA3N05-480A FE10
iC7-60EA3N05-588A FE10

10.7.4 Current Ratings for 6-pulse Enclosed Drives, FE9 and FE10, 500 V AC

Danfoss A/S © 2023.09
Nominal ratings
I [A] I [A] I [A]
N-in N peak
203 211 289
241 251 351
297 309 417
379 394 514
472 490 655
578 601 816
Nominal ratings
I [A] I [A] I [A]
N-in N peak
185 201 283
227 245 334
285 309 408
343 372 514
430 466 619
490 531 776
Low overload High overload
I [A] I [A] I [A] I
L-in L H-in H
199 206 164 170
236 245 199 206
291 302 236 245
371 385 291 302
463 480 371 385
567 588 463 480
Low overload High overload
I [A] I [A] I [A] I
L-in L H-in H
196 206 154 166
240 245 181 196
302 302 222 240
364 385 279 302
456 480 336 364
520 588 421 456
Specifications
Typical motor power, 400 V AC
[A] P [kW] P [kW]
L H
110 90
132 110
160 132
200 160
250 200
315 250
Typical motor power, 480 V AC
[A] P [Hp] P [Hp]
L H
150 125
200 150
250 200
300 250
350 300
450 350
AQ330347384398en-000201 / 139Z8096 | 103
