Input Fuses

All drives must have input fuses installed in the power supply to the
drive. These fuses may be specified as an option to the drive and
supplied by Danfoss Graham. If specified, they will be installed by
Danfoss Graham in an enclosure external to the drive which may
include other optional features. If not supplied by Danfoss Graham,
they must be supplied by the installer of the drive at the time of
installation.
208 Volt Input
Model Number VLT Type
VLT6000C4.6 6002
VLT6000C6.6 6003
VLT6000C7.5 6003
VLT6000C11 6004
VLT6000C17 6006
VLT6000C24 6008
VLT6000C31 6011
VLT6000C46 6016
VLT6000C59 6022
VLT6000C75 6027
VLT6000C88 6032
VLT6000C114 6042
VLT6000C143 6052
VLT6000C169 6062
460 Volt Input
Model Number VLT Type
VLT6000H2.1 6002
VLT6000H3.0 6002
VLT6000H3.4 6003
VLT6000H4.8 6004
VLT6000H8.2 6006
VLT6000H11 6008
VLT6000H14 6011
VLT6000H21 6016
VLT6000H27 6022
VLT6000H34 6027
VLT6000H40 6032
VLT6000H52 6042
VLT6000H65 6052
VLT6000H77 6062
VLT6000H106 6075
VLT6000H130 6100
VLT6000H160 6125
VLT6000H190 6150
VLT6000H240 6175
VLT6000H302 6225
VLT6000H361 6275
VLT6000H443 6350
VLT6000H540 6400
VLT6000H590 6500
VLT6000H678 6550
Maximum Fuse
Rating Bussman Type
10 KTN-R or JJN
15 KTN-R or JJN
20 KTN-R or JJN
25 KTN-R or JJN
50 KTN-R or JJN
50 KTN-R or JJN
50 KTN-R or JJN
60 KTN-R or JJN
80 KTN-R or JJN
125 KTN-R or JJN
125 KTN-R or JJN
150 FWX or FWH
200 FWX or FWH
250 FWX or FWH
Maximum Fuse
Rating Bussman Type
6 KTS-R or JJS
6 KTS-R or JJS
10 KTS-R or JJS
10 KTS-R or JJS
20 KTS-R or JJS
25 KTS-R or JJS
30 KTS-R or JJS
40 KTS-R or JJS
40 KTS-R or JJS
50 KTS-R or JJS
60 KTS-R or JJS
80 KTS-R or JJS
100 KTS-R or JJS
125 KTS-R or JJS
150 FWH
200 FWH
250 FWH
300 FWH
350 FWH
400 FWH
500 FWH
600 FWH
700 FWH
800 FWH
800 FWH
All fuse ratings are in amps
The required type of fuse for each drive size is shown in the table
below. The fuse rating shown is both the maximum and the recom-
mended fuse rating.
The drives are suitable for use on circuits capable of delivering not
more than 100,000 RMS symmetrical amps, 500 volts maximum (600
volts maximum for 575 volt drives), when used with the recommended
fuses.
575 Volt Input
Mode l Num ber VLT Type
VLT6000J2.7 6016
VLT6000J3.9 6016
VLT6000J6.1 6016
VLT6000J9 6016
VLT6000J11 6016
VLT6000J17 6016
VLT6000J22 6022
VLT6000J27 6027
VLT6000J32 6032
VLT6000J41 6042
VLT6000J52 6052
VLT6000J62 6062
All fuse ratings are in amps
Ma x im um Fuse
Ra ting Bussm a n Type
6 KTS-R or similar
6 KTS-R or similar
10 KTS-R or similar
20 KTS-R or similar
25 KTS-R or similar
40 KTS-R or similar
40 KTS-R or similar
50 KTS-R or similar
60 KTS-R or similar
80 KTS-R or similar
100 KTS-R or similar
125 KTS-R or similar
7
