iC7-Automation Air-cooled Enclosed Drives
Operating Guide
Table 39: External Fuses of the Enclosed Drives
Model code
iC7-60EA3N05-206A
iC7-60EA3N05-245A
iC7-60EA3N05-302A
iC7-60EA3N05-385A
iC7-60EA3N05-480A
iC7-60EA3N05-588A
iC7-60EA3A05-385A
iC7-60EA3A05-480A
iC7-60EA3A05-588A
iC7-60EA3A05-658A
iC7-60EA3A05-730A
iC7-60EA3A05-820A
iC7-60EA3A05-880A
iC7-60EA3A05-1000
iC7-60EA3A05-1100
with the mains contactor option
1

10.7 Current Ratings

10.7.1 Current Rating Table List

The current rating tables show the ratings of the enclosed drives at relevant voltage ratings. The current rating tables for the differ-
ent products can be found with these links.
• 10.7.2 Current Ratings for 6-pulse Enclosed Drives, FE9 and FE10, 400 V AC
• 10.7.3 Current Ratings for 6-pulse Enclosed Drives, FE9 and FE10, UL, 460 V AC
• 10.7.4 Current Ratings for 6-pulse Enclosed Drives, FE9 and FE10, 500 V AC
• 10.7.5 Current Ratings for Regenerative AFE, 400 V AC
• 10.7.6 Current Ratings for Regenerative AFE, UL, 460 V AC
• 10.7.7 Current Ratings for Regenerative AFE, 500 V AC
• 10.7.8 Current Ratings for Low-harmonic AFE, 400 V AC
• 10.7.9 Current Ratings for Low-harmonic AFE, UL, 460 V AC
• 10.7.10 Current Ratings for Low-harmonic AFE, 500 V AC
Table 40: Abbreviations Used in the Rating Tables
Abbrevia- Description
tion
I Nominal current. If the process does not require any overloadability or the process does not include any load var-
N
iation or margin for overloadability, the dimensioning can be done according to this current.
I
Nominal current with low overload (110%). Allows a +10% load variation for 1 minute every 5 minutes.
L
102 | Danfoss A/S © 2023.09
Frame
FE9, FE10
FE9, FE10
FE9, FE10
FE9, FE10
FE9, FE10
FE9, FE10
AE10 + IE10
AE10 + IE10
AE10 + IE10
AE11 + IE11
AE11 + IE11
AE11 + IE11
AE11 + IE11
2xAE10 + 2xIE10
2xAE10 + 2xIE10
IEC fuse
gG 315 A or gG 355 A
(1)
gG 315 A
gG 400 A
gG 500 A
gG 630 A
gG 630 A
gG 1000 A
gG 1250 A
Specifications
UL fuse
–
–
–
–
–
–
Class J, 600 A
Class J/L, 800 A
Class L, 1200 A
–
–
AQ330347384398en-000201 / 139Z8096
