iC7-Automation Air-cooled Enclosed Drives
Operating Guide
Model code Frame
iC7-60EA3A05-658A AE11+IE11
iC7-60EA3A05-730A AE11+IE11
iC7-60EA3A05-820A AE11+IE11
iC7-60EA3A05-880A AE11+IE11
iC7-60EA3A05-1000 2 x AE10+2 x IE10
iC7-60EA3A05-1100 2 x AE10+2 x IE10
iC7-60EA3A05-1260 2 x AE11+2 x IE11
iC7-60EA3A05-1450 2 x AE11+2 x IE11
iC7-60EA3A05-1710 2 x AE11+2 x IE11

10.7.7 Current Ratings for Regenerative AFE, 500 V AC

Table 46: Current Ratings for Regenerative AFE, 500 V AC
Model code Frame
iC7-60EA3A05-385A AE10+IE10
iC7-60EA3A05-480A AE10+IE10
iC7-60EA3A05-588A AE10+IE10
iC7-60EA3A05-658A AE11+IE11
iC7-60EA3A05-730A AE11+IE11
iC7-60EA3A05-820A AE11+IE11
iC7-60EA3A05-880A AE11+IE11
iC7-60EA3A05-1000 2 x AE10+2 x IE10
iC7-60EA3A05-1100 2 x AE10+2 x IE10
iC7-60EA3A05-1260 2 x AE11+2 x IE11
iC7-60EA3A05-1450 2 x AE11+2 x IE11
iC7-60EA3A05-1710 2 x AE11+2 x IE11

10.7.8 Current Ratings for Low-harmonic AFE, 400 V AC

Danfoss A/S © 2023.09
Nominal ratings
I [A] I [A] I [A]
N-in N peak
500 603 833
554 672 930
604 746 1031
704 838 1158
755 940 1299
855 1052 1454
955 1174 1632
1106 1328 1836
1306 1603 2227
Nominal ratings
I [A] I [A] I [A]
N-in N peak
322 372 510
406 466 619
457 531 776
518 603 833
583 672 930
647 746 1031
725 838 1158
815 940 1299
919 1052 1454
1034 1174 1632
1164 1328 1836
1422 1603 2227
Low overload High overload
I [A] I [A] I [A] I
L-in L H-in H
489 590 344 490
542 658 443 547
591 730 492 606
688 820 542 681
738 920 591 764
837 1030 640 855
935 1150 738 960
1082 1300 837 1080
1279 1570 1082 1310
Low overload High overload
I [A] I [A] I [A] I
L-in L H-in H
315 364 254 300
397 456 315 364
447 520 397 456
506 590 399 490
570 658 450 547
633 730 506 606
709 820 570 681
797 920 633 764
899 1030 709 855
1012 1150 797 960
1139 1300 899 1080
1392 1570 1012 1310
AQ330347384398en-000201 / 139Z8096 | 105
Specifications
Typical motor power,
480 V AC
[A] P [Hp] P [Hp]
L H
500 350
550 450
600 500
700 550
750 600
850 650
950 750
1100 850
1300 1100
Typical motor power,
500 V AC
[A] P [kW] P [kW]
L H
250 200
315 250
355 315
400 315
450 355
500 400
560 450
630 500
710 560
800 630
900 710
1100 800
