10.4.1 STO/SS1 Push Button on Door (+ILSS)

The STO inputs are wired to the (-SFG) emergency stop push button on the control compartment door. External emergency stop
push buttons can be connected to the same circuit. Remove the saddle jumpers XDJ:3-XDJ:5 and XDJ:4-XDJ:6 and connect the ex-
ternal emergency stop push button to these terminals according to the circuit diagram.
If option +ILSS is not selected, inputs A+ and B+ are connected to 24 VDC on -XD2.2 terminal block with saddle jumpers. Without
option +ILSS or an external emergency stop push button, the STO inputs can be used for the STO safety function. See details in the
iC7 Series Functional Safety Operating Guide.
94 | Danfoss A/S © 2023.09
Plus code Description
+IHAT Aux AC voltage transformer
+IHAS Aux AC supply terminals
+IICD Run, ready, fault
+ILSS STO/SS1 push button on door
+KCIB Mains cabling from bottom
+KCIT Mains cabling from top
+KDOB Motor cabling from bottom
+KDOT Motor cabling from top
+KFCP Plate with no holes
+MAC2 Common-mode Filter
+MAU1 dU/dt Filter
+MAU2 dU/dt Filter w/ CM filter
+OABC Back-channel cooling
+OAOF Cooling air output flange
+QALS Lifting support for power unit
+AFMC Marine Construction
