Illustration 32: Fiber Cable Connection from the Control of the Module to the Control Board of the Control Compartment
1
Control board of the module
2
Control board of the control compartment
7.8 Control Cable Routing
Use the control cable grommets and tubes to route the control cables into the control compartment. There are control cable grom-
mets at the top and at the bottom of the cabinet.
