Illustration 57: Dimensions for the Cooling Air Output Flange Option (+OAOF), AE10, AE11, IE10, and IE11, in mm (in)
Table 31: Dimensions in mm (in)
W W1
400 (15.7) 203 (8.0)
600 (23.6) 190 (7.5)
800 (31.5) 185 (7.3)

10.3 Wiring Diagrams

10.3.1 Wiring Diagram, FE9, FE10

82 | Danfoss A/S © 2023.09
170.8
(6.724)
Ø200
(7.87)
W3
W2
W1
2442.1
(96.146)
W2 W3
– –
225 (8.9) –
218 (8.6) 218 (8.6)
130
(5.12)
W5
W4
W4 W5
280 (11.0) 203 (8.0)
220 (8.7) 173 (6.8)
310 (12.2) 218 (8.6)
AQ330347384398en-000201 / 139Z8096
Specifications
102.2
(4.024)
W6
W6
–
260 (10.2)
370 (14.6)
