iC7-Automation Air-cooled Enclosed Drives
Operating Guide
Model code Frame
iC7-60EA3N05-385A
iC7-60EA3N05-480A FE10
iC7-60EA3N05-588A
iC7-60EA3A05-385A AE10 + IE10
iC7-60EA3A05-480A
iC7-60EA3A05-588A
iC7-60EA3A05-658A AE11 + IE11
iC7-60EA3A05-730A
iC7-60EA3A05-820A
iC7-60EA3A05-880A
iC7-60EA3A05-1000 2xAE10 +
2xIE10
iC7-60EA3A05-1100
iC7-60EA3A05-1260 2xAE11 +
2xIE11
iC7-60EA3A05-1450
iC7-60EA3A05-1710
Cable lugs installed on both sides of the fixing hole
1
10.5.5 Motor Cable Size Recommendation, UL 480 V
Table 36: Motor Cable Size Recommendation, UL 480 V
Model code Frame
iC7-60EA3N05-206A FE9
iC7-60EA3N05-245A
iC7-60EA3N05-302A
iC7-60EA3N05-385A
iC7-60EA3N05-480A FE10
iC7-60EA3N05-588A
iC7-60EA3A05-385A AE10 + IE10
iC7-60EA3A05-480A
Danfoss A/S © 2023.09
I [A] Mains cable Cable termina-
N
Cu tion, Panduit ter-
minal part num-
ber
385 2 x 300 MCM LCAX300-12-6
480 3 x 300 MCM LCAX300-12-6
588 3 x 300 MCM LCAX300-12-6
303 2 x 4/0 AWG LCAX4/0-12-X
352 2 x 250 MCM LCAX250-12-X
451 3 x 4/0 AWG LCAX4/0-12-X
500 3 x 250 MCM LCAX250-12-X
554 3 x 300 MCM LCAX300-12-6
604 3 x 350 MCM LCAX350-12-6
704 4 x 250 MCM LCAX250-12-X
755 4 x 300 MCM LCAX300-12-6
855 4 x 350 MCM LCAX350-12-6
955 6 x 4/0 AWG LCAX4/0-12-X
1106 6 x 300 MCM LCAX300-12-6
1306 6 x 350 MCM LCAX350-12-6
I [A] Motor cable, Cable termina-
N
Cu tion, Panduit ter-
minal part num-
ber
206 2x300 MCM LCAX300-12-6
245 2x300 MCM LCAX300-12-6
302 2x300 MCM LCAX300-12-6
385 2x300 MCM LCAX300-12-6
480 3x300 MCM LCAX300-12-6
588 3x300 MCM LCAX300-12-6
372 2x 300 MCM LCAX300-12-6
466 3x 4/0 AWG LCAX4/0-12-X
Maximum Maximum
cable size number of
mains ca-
bles (hole
(1)
size of the
mains termi-
nal [mm])
300 MCM 2 (Ø10.5)
300 MCM 3 (Ø13.5)
300 MCM 3 (Ø13.5)
500 MCM - (Ø13.5)
500 MCM - (Ø13.5)
500 MCM - (Ø13.5)
500 MCM 4 (Ø10.5)
500 MCM 4 (Ø10.5)
500 MCM 4 (Ø10.5)
500 MCM 4 (Ø10.5)
500 MCM 4 (Ø10.5)
500 MCM 4 (Ø10.5)
500 MCM 8 (Ø10.5)
500 MCM 8 (Ø10.5)
500 MCM 8 (Ø10.5)
Maximum Maximum
cable size number of
motor ca-
bles (bolt
size)
300 MCM 2 (M10)
300 MCM 2 (M10)
300 MCM 2 (M10)
300 MCM 2 (M10)
300 MCM 3 (M10)
300 MCM 3 (M10)
500 MCM 4 (M10)
500 MCM 4 (M10)
AQ330347384398en-000201 / 139Z8096 | 99
Specifications
Number of
grounding
holes on PE
busbar (hole
size [mm])
2 (Ø10.5)
4 (Ø10.5)
4 (Ø10.5)
4 (Ø10.5)
4 (Ø10.5)
4 (Ø10.5)
5 (Ø10.5)
5 (Ø10.5)
5 (Ø10.5)
5 (Ø10.5)
5 (Ø10.5)
5 (Ø10.5)
8 (Ø10.5)
8 (Ø10.5)
8 (Ø10.5)
Number of
grounding
holes on PE
busbar (hole
size [mm])
(1)
2 (Ø10.5)
2 (Ø10.5)
2 (Ø10.5)
2 (Ø10.5)
4 (Ø10.5)
4 (Ø10.5)
4 (Ø10.5)
4 (Ø10.5)
