iC7-Automation Air-cooled Enclosed Drives
Operating Guide
Terminal Function Description
19 DGND
Digital input ground, not isolated by default.
When using the internal +24 V
20 DGND
When using the external +24 V DC supply, remove the external jump wire between DGND and GND.
21 DO 1
Configurable digital output.
Push-pull 24 V/50 mA
22 DO 2
Open collector (NPN/PNP) 48 V/50 mA
Short-circuit protected
23 GND
I/O ground.
Ground for digital outputs, +10 V Ref, +24 V
24 GND
31 AO 1
Configurable analog output.
Voltage mode:
•
•
•
•
Current mode:
•
•
•
•
32 +10 V ref. 10 V (0...+3%), maximum current 10 mA
33 AI 1
Configurable analog input.
Voltage mode:
34 AI 2
•
•
•
•
Current mode:
•
•
•
•
35 GND
I/O ground.
Ground for digital outputs, +10 V Ref, +24 V
36 GND
37 GND
38 GND
46 | Danfoss A/S © 2023.09
out
0...10 V
R ≥ 1 kΩ
L
accuracy ≤ ± 0.5% of full scale
short-circuit protected
0...20 mA
R ≤ 600 Ω
L
accuracy ≤ ± 0.5% of full scale
short-circuit protected
0 ± 10 V
single-ended
R ~ 10 kΩ
i
accuracy ± 0.5% of full scale
0 ± 20 mA
differential
R ~ 200 Ω
i
accuracy ± 0.5% of full scale
supply, connect the external jump wire between DGND and GND.
, analog inputs, and analog outputs.
out
, analog inputs, and analog outputs.
out
Control and Option Installation
