iC7-Automation Air-cooled Enclosed Drives
Operating Guide
600
(23.6)
Illustration 48: Dimensions of the Enclosed Drive, FE10, in mm (in)
A Mounting holes at the bottom
B Mounting holes at the top

10.2.3 Dimensions of the Enclosed Drive, AE10, AE11, IE10, IE11

72 | Danfoss A/S © 2023.09
683
(26.8)
733
(28.8)
2302
(90.6)
646
(25.4)
A
30
(1.19)
592
(23.3)
Ø13
(0.51)
17
(0.67)
2202
(86.7)
200
(7.87)
49
2xØ11
(1.93)
(0.43)
Ø13
(0.51)
510
(20.1)
20
(0.79)
Specifications
B
17
(0.67)
2xØ5.5
(0.22)
B
A
20
(0.79)
AQ330347384398en-000201 / 139Z8096
