iC7-Automation Air-cooled Enclosed Drives
Operating Guide
Model code Frame
iC7-60EA3A05-658A AE11 + IE11
iC7-60EA3A05-730A
iC7-60EA3A05-820A
iC7-60EA3A05-880A
iC7-60EA3A05-1000 2xAE10 +
2xIE10
iC7-60EA3A05-1100
iC7-60EA3A05-1260 2xAE11 +
2xIE11
iC7-60EA3A05-1450
iC7-60EA3A05-1710
current, prospective, minimum rating
1
Bussmann
2
Mersen
3
Double fuse per phase
4
10.6.3 DC Fuses, 465–800 V DC
Table 38: DC Fuses, 465–800 V DC
Model code Frame
iC7-60EA3A05-385A AE10 + IE10
iC7-60EA3A05-480A AE10 + IE10
iC7-60EA3A05-588A AE10 + IE10
iC7-60EA3A05-658A AE11 + IE11
iC7-60EA3A05-730A AE11 + IE11
iC7-60EA3A05-820A AE11 + IE11
iC7-60EA3A05-880A AE11 + IE11
iC7-60EA3A05-1000 2xAE10 + 2xIE10
iC7-60EA3A05-1100 2xAE10 + 2xIE10
iC7-60EA3A05-1260 2xAE11 + 2xIE11
iC7-60EA3A05-1450 2xAE11 + 2xIE11
iC7-60EA3A05-1710 2xAE11 + 2xIE11

10.6.4 External Fuses on External Supply for input devices

The enclosed drives with a mains contactor or a main switch must be protected with external fuses. The fuses in the table meet the
IEC type 1 coordination for contactor short circuit current performance and are required for main switch protection.
Danfoss A/S © 2023.09
Rated Number Fuse
current of fuses size
I [A]
L
658 6 33
(4)
730 6 33
(4)
820 6 33
(4)
880 6 33
(4)
1000 6 33
1100 6 33
1260 12 33
(4)
1450 12 33
(4)
1707 12 33
(4)
Rated cur- Number of
rent I [A] fuses
L
385 2
480 2
588 2
658 2
730 2
820 2
880 2
1000 8
1100 8
1260 8
1450 8
1707 8
Part number Fuse U
[V]
PC33UD69V550TF 690
(3)
PC33UD69V550TF 690
(3)
PC33UD69V550TF 690
(3)
PC33UD69V550TF 690
(3)
PC33UD69V700TF 690
(3)
PC33UD69V700TF 690
(3)
PC33UD69V550TF 690
(3)
PC33UD69V550TF 690
(3)
PC33UD69V550TF 690
(3)
Fuse size Part number
73 PC73UD13C630TF
73 PC73UD13C800TF
73 PC73UD10C1000TF
73 PC73UD90V13CTF
73 PC73UD90V13CTF
73 PC73UD85V14CTF
73 PC73UD85V14CTF
73 PC73UD13C800TF
73 PC73UD10C1000TF
73 PC73UD90V13CTF
73 PC73UD90V13CTF
73 PC73UD85V14CTF
AQ330347384398en-000201 / 139Z8096 | 101
Specifications
Fuse I I [A]
n n cp,mr
[A]
(1)
550 6576
550 6576
550 6576
550 6576
700 –
700 –
550 –
550 –
550 –
Fuse U Fuse I [A]
n n
[V]
1250 630
1250 800
1000 1000
900 1250
900 1250
850 1400
850 1400
1250 800
1000 1000
900 1250
900 1250
850 1400
