iC7-Automation Air-cooled Enclosed Drives
Operating Guide
Table 47: Current Ratings for Low-harmonic AFE, 400 V AC
Model code Frame
iC7-60EA3H05-385A AE10+IE10
iC7-60EA3H05-480A AE10+IE10
iC7-60EA3H05-588A AE10+IE10
iC7-60EA3H05-658A AE11+IE11
iC7-60EA3H05-730A AE11+IE11
iC7-60EA3H05-820A AE11+IE11
iC7-60EA3H05-880A AE11+IE11
iC7-60EA3H05-1000 2 x AE10+2 x IE10
iC7-60EA3H05-1100 2 x AE10+2 x IE10
iC7-60EA3H05-1260 2 x AE11+2 x IE11
iC7-60EA3H05-1450 2 x AE11+2 x IE11
iC7-60EA3H05-1710 2 x AE11+2 x IE11

10.7.9 Current Ratings for Low-harmonic AFE, UL, 460 V AC

Table 48: Current Ratings for Low-harmonic AFE, UL, 460 V AC
Model code Frame
iC7-60EA3H05-385A AE10+IE10
iC7-60EA3H05-480A AE10+IE10
iC7-60EA3H05-588A AE10+IE10
iC7-60EA3H05-658A AE11+IE11
iC7-60EA3H05-730A AE11+IE11
iC7-60EA3H05-820A AE11+IE11
iC7-60EA3H05-880A AE11+IE11
iC7-60EA3H05-1000 2 x AE10+2 x IE10
iC7-60EA3H05-1100 2 x AE10+2 x IE10
iC7-60EA3H05-1260 2 x AE11+2 x IE11
iC7-60EA3H05-1450 2 x AE11+2 x IE11
iC7-60EA3H05-1710 2 x AE11+2 x IE11

10.7.10 Current Ratings for Low-harmonic AFE, 500 V AC

106 | Danfoss A/S © 2023.09
Nominal ratings
I [A] I [A] I [A]
N-in N peak
325 394 510
403 490 655
508 601 816
571 672 930
647 746 1031
728 838 1158
809 899 1243
905 1021 1411
1018 1123 1553
1148 1287 1785
1293 1481 2057
1453 1746 2414
Nominal ratings
I [A] I [A] I [A]
N-in N peak
303 372 510
352 466 619
451 531 776
500 603 833
554 672 930
604 746 1031
704 838 1158
755 940 1299
855 1052 1454
955 1174 1632
1106 1328 1836
1306 1603 2227
Low overload High overload
I [A] I [A] I [A] I
L-in L H-in H
317 385 254 300
394 480 317 385
497 588 394 480
559 658 394 547
633 730 499 606
712 820 562 681
791 880 633 731
886 1000 712 830
997 1100 791 913
1123 1260 886 1050
1265 1450 997 1210
1423 1710 1123 1420
Low overload High overload
I [A] I [A] I [A] I
L-in L H-in H
296 364 247 300
344 456 296 364
441 520 344 456
489 590 344 490
542 658 443 547
591 730 492 606
688 820 542 681
738 920 591 764
837 1030 640 855
935 1150 738 960
1082 1300 837 1080
1279 1570 1082 1310
AQ330347384398en-000201 / 139Z8096
Specifications
Typical motor power,
400 V AC
[A] P [kW] P [kW]
L H
200 160
250 200
315 250
355 250
400 315
450 355
500 400
560 450
630 500
710 560
800 630
900 710
Typical motor power,
480 V AC
[A] P [Hp] P [Hp]
L H
300 250
350 300
450 350
500 350
550 450
600 500
700 550
750 600
850 650
950 750
1100 850
1300 1100
